Chapter 2 Front Panel Operations RIGOL
DP800 User Guide 2-23
3. Edit the timer parameters
For different templets, the timer parameters to be set are different as shown in
Table 2-1.
Table 2-1 Timer parameters (templet)
Max Value, Min Value, Points, Interval, Inverted
Hi Level, Lo Level, Width, Period, Inverted
Max Value, Min Value, Points, Interval, Symmetry, Inverted
Max Value, Min Value, Points, Interval
Max Value, Min Value, Points, Interval
Max Value, Min Value, Points, Interval
Max Value, Min Value, Points, Interval, Rise Index
Max Value, Min Value, Points, Interval, Fall Index
Max Value
Set the maximum voltage or current of the templet currently selected. The
range is related to the channel currently selected. It should be greater than
or equal to the minimum value currently set.
Min Value
Set the minimum voltage or current of the templet currently selected. The
range is related to the channel currently selected. It should be lower than or
equal to the maximum value currently set.
Points
Set the total number of points (namely the number of output groups in the
timer parameters) of the templet currently selected. The range is from 10 to
2048.
When the total number of points (denoted by P) and the current number of
output groups (denoted by G) are different, the number of output groups
will change to P automatically after output waveform is created using the
templet.
Interval
Set the time interval between the points (the time required for the
instrument to output each group of timer parameters) of the templet
currently selected. The range is from 1s to 99999s.
Inverted
When the templet currently selected is Sine, Pulse or Ramp, if invert is
enabled, the instrument will first turn the preset waveform upside down
and then create the output waveform.
