RIGOL Chapter 2 Command System
2-8 DP800 Programming Guide
:DELAY:ENDState
Syntax :DELAY:ENDState {ON|OFF|LAST}
:DELAY:ENDState?
Description Set the end state of the delayer to On, Off or Last.
Query the end state of the delayer.
Parameter
Name Type Range Default
{ON|OFF|LAST} Discrete ON|OFF|LAST OFF
Explanation  The end state refers to the state of the instrument when the delayer stops.
 ON: output on, the instrument turns on the output automatically; OFF: output
off, the instrument turns off the output automatically; LAST: last state, the
instrument stops at the output state of the last group.
 The total number of groups in each delay output = the number of groups × the
number of cycles. Wherein, the number of groups is set by the
:DELAY:GROUPs
command and the number of cycles is set by the
:DELAY:CYCLEs command.
Return Format The query returns ON, OFF or LAST.
Example :DELAY:ENDS LAST /*Set the end state to Last*/
:DELAY:ENDS? /*Query the current end state and the query returns LAST */
Related
Commands
:DELAY:GROUPs
:DELAY:CYCLEs
:DELAY:GROUPs
Syntax :DELAY:GROUPs <value>
:DELAY:GROUPs?
Description Set the number of output groups of the delayer.
Query the number of output groups of the delayer.
Parameter
Name Type Range Default
<value> Integer 1 to 2048 1
Explanation  The number of output groups refers to the number of times that the
instrument turns on or off the output according to the preset state.
 The total number of groups in each delay output = the number of groups × the
number of cycles. Wherein, the number of cycles is set by the
:DELAY:CYCLEs
command.
 The power supply will terminate the delayer function when the total number of
groups of delays is finished. At this point, the state of the power supply
depends on the setting of the :DELAY:ENDState command.
Return Format The query returns an integer from 1 to 2048.
Example :DELAY:GROUP 125 /*Set the number of groups to 125*/
:DELAY:GROUP? /*Query the current number of groups and the query
returns 125*/
Related
Commands
:DELAY:CYCLEs
:DELAY:ENDState
