Chapter 2 Front Panel Operations RIGOL
DP800 User Guide 2-27
To Set the Number of Cycles
The number of cycles refers to the number of times that the instrument performs
delay output according to the preset state. Press Cycles to set the number of cycles
to "Infinite" or use the numeric keyboard or the left/right arrow key and knob to
input the desired value. The range is from 1 to 99999.
To Set the End State
The end state refers to the state of the instrument when the delay function is
terminated. Press End State to select "Outp On", "Outp Off" or "Last".
Outp On: the instrument turns on the output automatically.
Outp Off: the instrument turns off the output automatically.
Last: the instrument stops at the output state of the last group.
To Edit the Delay Parameters
You can edit the delay parameters manually or generate the delay parameters
automatically using the built-in pattern and built-in method.
To Edit the Delay Parameters Manually
You need to set P groups (No.0 to No.(P-1)) of delay parameters; wherein, P is the
number of output groups currently set. Only 6 groups of parameters can be
displayed on each page of the delayer parameter list and you can press
or
to view and set the parameters of the other groups. This interface provides delay
parameter preview and users can view the values on the current page of the delay
parameter list (high level indicates turning on the output and low level indicates
turning off the output).
1. Press Parameter and use the numeric keyboard or the left/right arrow key or
the knob to select the specified number (No.) in the delay parameter list.
The total number of groups in delay output = the number of output
groups*the number of cycles
The power supply will terminate the delay function when the instrument
detects the state that meets the condition set in "To Set the Stop
Condition" or when the total number of groups of delay outputs is finished.
At this point, the state of the power supply depends on the setting in "
To Set
