Rigol DS2000E Series User Manual

RIGOL Chapter 6 MATH and Measurements
6-16 DS2000E User’s Guide
One-key Measurement of 29 Parameters
Press MENU at the left of the screen to turn on the measurement menu of the 29
parameters and then press the corresponding menu softkey to quickly realize
"One-key" measurement. The measurement result will be displayed at the bottom of
the screen.
Note: Press Measure  Source to select the current measurement source.
The menu item icons and measurement results of time, voltage and area parameters
are always in the same color as the current measurement channel (Measure 
Source). The menu item icons and measurement results of delay and phase
parameters are always indicated in white; the menu item icons and the number in
the results denote source A and source B currently selected (the color of the number
is the same as that of the selected channel).
Note: If the measurement result is displayed as "*****", there is no signal input into
the current measurement source or the measurement result is out of the valid range
(too large or too small).
