Chapter 12 Store and Recall RIGOL
DS2000E User’s Guide 12-15
Factory
Press Storage Default to return the oscilloscope to its factory state (refer to the
table below).
Table 12-2 Factory
Parameter Factory
Horizontal Setting (HORIZONTAL)
Vertical Setting (VERTICAL)
Acquisition Setting (Acquire)
Trigger Setting (TRIGGER)
Display Setting (Display)
Cursor Setting (Cursor)
Storage Setting (Storage)
Utility Function Setting (Utility)
Math Operation Setting (MATH->Operate)
Protocol Decoding (Decode 1, Decode 2)
Reference Waveform Setting (REF)
Horizontal Setting (HORIZONTAL)
Horizontal Time Base 1 μs
Horizontal Offset 0 s
Delayed Sweep OFF
Time Base Type Y-T
Time Base Scale Coarse
Horizontal Reference The Center of the Screen
Vertical Setting (VERTICAL)
Vertical Scale 1 V
Vertical Offset 0 V
CH1 Switch ON
CH2 Switch ON
Channel Coupling DC
Bandwidth Limit OFF
Probe Ratio 1X
Input Impedance 1 MΩ
To Next Page
