Rigol DS2000E Series User Manual

RIGOL Chapter 12 Store and Recall
12-16 DS2000E User’s Guide
Channel Invert OFF
Amplitude Scale Coarse
Channel Unit V
Acquisition Setting (Acquire)
Acquisition Mode Normal
Sampling Mode Real Time
Memory Depth Auto
Anti-Aliasing OFF
Trigger Setting (TRIGGER)
Trigger Level 0
Trigger Type Edge
Source CH1
Slope Rising Edge
Trigger Mode Auto
Trigger Coupling DC
Trigger Holdoff 100 ns
Noise Reject OFF
Display Setting (Display)
Display Type Vectors
Persistence Time Min
Waveform Intensity 50%
Screen Grid
Brightness 50%
Menu Display Infinite
Cursor Setting (Cursor)
Mode OFF
Manual
Display Mode X-Y
Source CH1
Screen Region Main
Time Unit s
Vertical Unit Source Unit
