Chapter 7 Protocol Decoding RIGOL

DS2000E User’s Guide 7-13

6. Error Expressions during Decoding

When the ACK (ACKnowledge Character) is not met, the red error marks as

shown in the figure below will be displayed. Note: The red mark is displayed in

different modes according to the horizontal time base setting; when the

horizontal time base is relatively smaller,

is displayed; otherwise, is

displayed.

Figure 7-9 Error Expressions during Decoding

ACK=1
