Rinstrum C530 User Manual

Parameter Description Range Default
1 Port 0 = Module 1A
1 = Module 1B
2 = Module 2A
3 = Module 2B
4 = TCP Net
5 = TCP Auto
6 = USB Slave Serial Port
7 = USB Host Serial Port
10 = Onboard Serial 1 (C520 only)
11 = UDP Outgoing 1
12 = UDP Outgoing 2
13 = UDP Incoming 1
14 = UDP Incoming 2
17 = Onboard Serial 2 (C520 only)
2 Type 0 = Off
1 = Auto Lo
2 = Auto Hi
3 = Print
4 = Single
5 = Network
6 = 5000 Modbus ASCII Legacy
7 = Modbus ASCII
8 = Modbus RTU
Availability:
 SER.1: Off - MB.LGCY
 SER.2: Off - MB.LGCY
 SER.M.xA: Off - MB.LGCY
 SER.M.xB: Off - Single
 SER.SLV: Off - Net
 SER.HST: Off - MB.RTU
 TCP.IN.1: Net (fixed)
 TCP.IN.2: Auto Lo - Auto Hi
 UDP.x: Off - Net
Default depends
on port.
3 Baud Rate 1 = 300
2 = 600
3 = 1200
4 = 2400
5 = 4800
6 = 9600
7 = 19200
8 = 38400
9 = 57600
10 = 115200
Setting applicable to onboard, module and USB
host serial ports.
6 (9600)
4 Parity 0 = None
1 = Odd
2 = Even
Setting applicable to onboard, module and USB
host serial ports.
0 (None)
125 C500-600-2.0.3
