Rinstrum C530 User Manual

Parameter Description Range Default
5 Data Bits 7, 8
Setting applicable to onboard, module and USB
host serial ports.
8
6 Stop Bits 1, 2
Setting applicable to onboard, module and USB
host serial ports.
1
7 Termination Resistors 0 = Off
1 = On
Setting applicable to onboard SER.1 and RS485
modules.
0 (Off)
8 DTR 0 = Off
1 = On
Setting applicable to onboard SER.2 and RS232
modules.
0 (Off)
9 Switch RS232/RS485 0 = RS485
1 = RS232
Setting applicable to onboard SER.1.
1
10 TCP/UDP Port TCP Ports: 1024 .. 65535
UDP Ports: 0 (disabled) .. 65535
Setting applicable to TCP and UDP ports.
TCP Net: 2222
TCP Auto: 2223
UDP Ports: 0
11 TCP Timeout 0 (disabled) .. 86400 seconds.
Setting applicable to TCP ports.
0
12 UDP Destination IP 0.0.0.0 (disabled) - 255.255.255.255
Setting applicable to outgoing UDP ports.
0.0.0.0
Example: Change baud rate settings of Unit 1, Module 1A to 19200
Command Answer Description
S01; Select unit 1
BDX?0; 0,5,6,0,8,1,0,0,1,0,0,"0.0.0.0"CRLF Query module 1A settings
BDX0,,7; 0 CRLF Baud rate changed
TDD1; 0 CRLF Save new settings
21.3.8 BRT: Display Brightness
Adjust the display brightness.
General
No. of parameters 1
Save changes With TDD1
Increment Trade Counter No
Parameter Details
Parameter Description Range Default
1 Display brightness 0 .. 100 100
Example
Command Answer Description
S01; Select unit 1
BRT?; 100 CRLF Query setting, brightness at 100%
BRT50; 0 CRLF Set brightness to 50%
TDD1; 0 CRLF Save new settings
126 C500-600-2.0.3
