ProSYS User's Manual 17
Zone LEDs
The Zone LEDs indicate the status of each of the system's intrusion zones.
For LCD keypads, the display indicates the zone's number and label.
Condition Description
System Disarmed System Armed
ON
N/A An alarm has occurred in
the indicated zone.
OFF
The corresponding zone
is secured.
FLASHING
The indicated zone is
not secured.
N/A
Keys
The keys on the keypad can be used for a variety of functions. Each key is
explained below.
Numerical Keys
Numerical keys are used to input the
numeric codes that may be required for
arming, disarming, and triggering
emergency alarms, along with several other
special functions.
Function Keys (A, B, C and D)
By default, Function keys are used to arm groups of zones, as defined by
your installer and described on page 24. Function keys can also be used to
activate a prerecorded series of commands, as described on page 52.
