100 WiNG-MGR User Guide 800.518.1519
E Technical Specifications
WiNG-RXT
RX A 1 green LED
RX B 1 green LED
TX/RX C 1 green LED
Diagnostics 1 green LED
System 1 multicolor LED
RO1 | RO2 1 green LED per relay output
RS485 Network Status 1 green LED for transmit, 1 Green LED for receive
RJ45 Network Status 2 green LEDs
Device Status 1 multicolor LED
Operating Environment
Temperature 32ºF to 122ºF (0ºC to 50ºC)
Humidity 5% to 95% RH non-condensing
Altitude 15,000ft (4572m) max.
9,842ft (3000m) max. if applying more than 150V, 50/60Hz
to the relays from overvoltage category II circuit.
Storage Temperature –4ºF to 185ºF (–20ºC to 85ºC)
Mounting 19" Rack Mount or Wall Mount
Dimensions 9.7"W x 4.8”D x 1.8"H (24.6cmW x 12.2cmD x 4.6cmH)
Weight 2.7lb (1.23kg)
Certifications ETL listed; CE; conforms to UL 61010-1, EN 61010;
certified to CSA C22.2 NO, 61010.1; RoHS compliant;
FCC ID X7J-A11072401 and MCQ-XB900HP; IC 8975A-
A11072401 and 1846A-XB900HP
Power 5VDC @ 400mA max.
USB Communications Port Serial port emulation for firmware upgrades and
diagnostics
Range Up to 1,000 ft (305m) indoors, direct line of sight to WiNG-
MGR or another WiNG-RXT.
Up to 600 ft (183m) direct line of sight to WiNG sensors.
Up to 270 ft (82.3m) through one wall to WiNG sensors.
Up to 100 ft (30.5m) through multiple walls to WiNG
sensors.
Indicators
Table E.2
WiNG-RXT Technical Specifications
Table E.1
WiNG-MGR Technical Specifications (continued)
