A PPENDIX
CHA PTER 3TECHNICAL SPECIFICATIONS
WiNG-MGR
Power
Voltage Rating 24VAC, 50/60Hz; 24VDC, 600mA
Current Rating 600mA max
Wired Relay Outputs Two (2) Dry Contact, Form C, 1A @ 24VDC resistive,
0.5A @ 120VAC
Communications Ports
Ethernet 10/100 BASE-T, RJ-45 connector; 500VAC RMS isolation
RS-232 DB9 female connector; 9600 baud; No parity, 8 data bits,
1 stop bit
RS-485 1200, 2400, 9600 or 19200 baud (selectable); Parity: none,
even or odd, 8 data bits, 1 stop bit
Protocols
TCP/IP, HTML, TFTP, SNMP V1: V2C MIB-2 compliant; NMS Manageable with Get
Modbus (EIA-485) Modbus Slave; RTU mode; Supports function codes 03
Modus TCP/IP UDP/IP Modbus Slave; TCP/IP transmission protocol
BACnet/IP ASHRAE STD 135-2004 Annex J
BACnet MS/TP RS-485
Wireless Communications
Frequency Range 868-870MHz / 902-928MHz
Max Number of Wireless Sensors
Per Manager
RLE recommends not exceeding 250 sensors per WiNG-
MGR; 400 sensors per WiNG-MGR may be accomplished
with range extenders, but signal conflict will increase.
Antenna Three (3) 868-928MHz with RP/SMA connectors
Web Interface Login Security Eight (8) users and passwords can be configured
Indicators
Table E.1 WiNG-MGR Technical Specifications
