3 Web Interface
3.6.3 BACnet
If the WiNG-MGR will communicate via the BACnet, configure the necessary options here.
Figure 3.21
BACnet Configuration
Option Description
Pics Click this link to view the Bacnet identifiers and objects supported by
the WiNG-MGR.
Packet Log Click this link to view the Bacnet packet log.
Device ID To enable BACnet, assign a unique number between 1 and 4194302
to identify this BACnet device on the network.
If you enter a 0 in this field BACnet will be disabled.
Default: 0 (Disabled)
Device Name Assign a name - up to 38 characters - to the unit for BACnet
discovery and integration.
Description Add any additional details about the device, up to 38 characters.
Location Designate the physical location of the unit.
UDP Port Enter a 0 to specify port 47808 (0xBAC0) as the UDP port. If another
port is specified by your application, enter that value here.
Default: 0 (47808)
BACnet/IP Read
Multiple
Use the toggle switch to enable or disable this option.
Default: Enabled
Register as Foreign
Device at IPv4
IP address of the master device with which you’re trying to
communicate. Requires a BBMD for foreign device discovery.
Table 3.12
BACnet Configuration Options
