102 WiNG-MGR User Guide 800.518.1519
E Technical Specifications
Typical Temperature +/- 0.3°C from -40°C to 85°C
Maximal Temperature +/- 0.4°C from -40°C to 85°C
Typical Humidity +/- 2% from 0%RH to 100%RH, 0°C to 85°C
Maximal Humidity +/- 3% from 0%RH to 100%RH at 25°C
NOTE: The sensor shows the best performance over the range of 20%RH to 80%RH, 5°C to
60°C. Prolonged exposure outside of that range will impact humidity accuracy.
Operating Environment
Temperature -13ºF to 185ºF (-25ºC to 85ºC)
Altitude -200ft to 15,000ft (-70m to 4572m) max.
Mounting Free standing, magnets (included), 1U screw, 15mm mini
din rail, zip ties
Dimensions 2.8"L x 1.1”W x 1.1"H (7.1cmL x 2.8cmW x 2.8cmH)
Weight 0.08lb (0.036kg)
Certifications CE; FCC ID XJ7-A11072401; IC 8975A-A11072401
Table E.3
WiNG Sensor Technical Specifications (continued)
