54 WiNG-MGR User Guide 800.518.1519
3 Web Interface
Trap Enter the appropriate community name.
Traps
Trap Type Select the SNMP version that best suits your needs: V1 - Trap, V2C
- Trap, V2C - Inform, V3 - Trap, or V3 - Inform.
IP Version Designate whether traps will be sent via IPv4 or IPv6.
Max. Inform Retries If the communication of a trap fails, this is the maximum number of
times the WiNG-MGR will re-send the trap.
Inform Interval This is the amount of time that lapses between re-sends.
Trap Destinations
Trap Enabled Check the box to allow a trap to be sent to the device defined in this
row.
IP Address This is the IP address of the device that the trap will be sent to.
SNMPv3 EngineID If this device uses SNMPv3, data will populate in this field.
SNMPv3
User Name Enter a unique name for each SNMPv3 user.
Access Mode Choose from the following:
No-Auth
Auth-MD5, No-Priv
Auth-MD5, Priv-DES
A user name is needed for No Authentication, and a user name and
password are required for Authentication and Privacy Authentication
access.
Auth. Password
(8-24 chars)
Enter the authentication password - the password must be between
8 and 24 characters long.
Priv. Password (8-24
chars)
Enter the privacy (encryption) password - the password must be
between 8 and 24 characters long.
Option Description
Table 3.16
SNMP Configuration Options
