Page 96.10 Chapter 96 Electrical System OCT 2014
96-100 Electrical Load Analysis (continued)
EQUIPMENT QTY
CONTINUOUS
AMPS EACH
INTERMITTENT
AMPS EACH
CONTINUOUS
TOTAL
INTERMITTENT
TOTAL
MAIN BUS (continued)
AVIONICS RELAY 1 --- 0.060 0.060
LOW FUEL RELAY 1 --- 0.010 0.010
WARNING LIGHT TEST CB 1 --- 0.020 0.020
TACH PWR TEST RELAY 1 --- 0.060 0.060
BOSE HEADSET 5 0.025 0.500 0.125 2.500
AUX POWER PLUG 1 2.000 2.000 2.000 2.000
EQUIPMENT QTY
CONTINUOUS
AMPS EACH
INTERMITTENT
AMPS EACH
CONTINUOUS
TOTAL
INTERMITTENT
TOTAL
LIGHTS BUS
LANDING LT BALLAST 2 1.600 5.250 3.200 10.500
LANDING LT RELAY 1 0.060 0.060 0.060 0.060
CIRCUIT BREAKER LTS 1 0.001 0.001 0.001 0.001
INSTRUMENT LT 1 0.500 0.500 0.500 0.500
POST LTS 2 0.040 0.040 0.080 0.080
INTERNAL AVIONICS LTS 6 0.100 0.100 0.600 0.600
COMPASS LIGHT (STD) 1 0.040 0.040 0.040 0.040
VERT CARD COMPASS LT 1 0.050 0.050 0.050 0.050
POSITION LT RH (GREEN) 1 0.250 0.250 0.250 0.250
POSITION LT LH (RED) 1 0.250 0.250 0.250 0.250
POSITION LT TAIL (WHT) 1 0.300 0.300 0.300 0.300
STROBE LIGHT 1 0.670 3.000 0.670 3.000
CLOCK LIGHT (STD) 1 0.040 0.040 0.040 0.040
EQUIPMENT QTY
CONTINUOUS
AMPS EACH
INTERMITTENT
AMPS EACH
CONTINUOUS
TOTAL
INTERMITTENT
TOTAL
AVIONICS BUS
KY196A COM 1 1.000 5.000 1.000 5.000
GNC 420W GPS/COM 1 1.215 4.200 1.215 4.200
GNS 530AW GPS/COM/NAV 1 1.415 4.400 1.415 4.400
GTX 330 XPDR 1 1.640 9.090 1.640 9.090
BLIND ENCODER 1 0.600 0.600 0.600 0.600
AM/FM/CD RCVR 1 1.500 1.500 1.500 1.500
KR87 ADF RCVR 1 0.429 0.429 0.429 0.429
KR22 MARKER BEACON 1 0.040 0.500 0.040 0.500
AVIONIC BLOWER 1 0.180 0.180 0.180 0.180
PILOT AV BLOWER 1 0.100 0.100 0.100 0.100
