96-100 Electrical Load Analysis (continued)
EQUIPMENT QTY
CONTINUOUS
AMPS EACH
INTERMITTENT
AMPS EACH
CONTINUOUS
TOTAL
INTERMITTENT
TOTAL
AVIONICS BUS (continued)
HSI (PICT NAV SYSTEM) 1 1.730 1.730 1.730 1.730
ATTITUDE HORIZON 1 0.270 0.700 0.270 0.700
TURN COORDINATOR 1 0.350 0.350 0.350 0.350
RADAR ALTIMETER 1 0.727 0.727 0.727 0.727
AMS42/44 AUDIO CNTRL 1 0.250 0.250 0.250 0.250
GTX 327 XPDR 1 1.640 5.450 1.640 5.450
GTX 328 XPDR 1 1.640 9.090 1.640 9.090
KX155A NAV/COM 1 0.940 6.000 0.940 6.000
KX165A NAV/COM 1 0.700 4.000 0.700 4.000
GPS 150XL 1 0.475 0.475 0.475 0.475
GNC 250XL GPS 1 1.215 4.950 1.215 4.950
GPS 400W 1 0.700 0.700 0.700 0.700
GI106A VOR/LOC/GS IND 1 0.100 0.100 0.100 0.100
KI203 VOR/LOC IND 1 0.075 0.075 0.075 0.075
KI204 VOR/LOC/GS IND 1 0.075 0.075 0.075 0.075
ATT HORIZON W/INCL 1 0.270 0.700 0.270 0.700
DIRECTIONAL GYRO 1 0.250 0.600 0.250 0.600
GNS 430W GPS/COM/NAV 1 1.215 4.200 1.215 4.200
GPS 500W 1 0.800 0.800 0.800 0.800
PA/SIREN & AMPLIFIER 1 0.005 4.000 0.005 4.000
ASPEN EFD 1000H 1 2.400 2.400 2.400 2.400
ASPEN EFD 500H 1 0.800 0.800 0.800 0.800
GTN 750 1 1.710 4.710 1.710 4.710
GTN 650 1 1.310 4.410 1.310 4.410
GTR 225B 1 0.280 2.600 0.280 2.600
GMA 350H 1 0.400 1.000 0.400 1.000
GTX 330ES 1 0.850 1.600 0.850 1.600
GDL 88 1 0.640 0.640 0.640 0.640
EQUIPMENT QTY
CONTINUOUS
AMPS EACH
INTERMITTENT
AMPS EACH
CONTINUOUS
TOTAL
INTERMITTENT
TOTAL
TACH BUS
N2 TACH (INCL REG) 1 0.022 0.022 0.022 0.022
N2 TACH @ 13.75V 1 0.035 0.035
ROTOR TACH (INCL REG) 1 0.022 0.022 0.022 0.022
ROTOR TACH @13.75V 1 0.035 0.035
OCT 2014 Chapter 96 Electrical System Page 96.11
