96-100 Electrical Load Analysis (continued)
EQUIPMENT QTY
CONTINUOUS
AMPS EACH
INTERMITTENT
AMPS EACH
CONTINUOUS
TOTAL
INTERMITTENT
TOTAL
OTHER EQUIPMENT
TACH RELAY 1 0.060 0.060 0.060 0.060
CLOCK (DIGITAL) 1 0.003 0.003 0.003 0.003
CLOCK (STD) 1 0.002 0.002 0.002 0.002
BATTERY RELAY 1 0.250 6.000 0.250 6.000
START/GEN RELAY 1 0.250 6.000 0.250 6.000
GEN LT RELAY 1 0.010 0.010 0.010 0.010
GEN CONTROL UNIT 1 0.200 2.000 0.200 2.000
ELT 1 --- ---
IGNITION EXCITER 1 --- 1.500 1.500
EXTERNAL PWR RELAY 1 0.250 6.000
BAGGAGE COMPARTMENT LT2 1 0.020 0.020
SIGHT GLASS LED 2 0.020 0.020
LATCHING START RELAY 1 0.060 0.060
STARTER-GENERATOR 1 --- 231.000
EQUIPMENT QTY
CONTINUOUS
AMPS EACH
INTERMITTENT
AMPS EACH
CONTINUOUS
TOTAL
INTERMITTENT
TOTAL
AIR CONDITIONING
COMPRESSOR 1 3.000 3.000 3.000 3.000
EVAPORATOR BLOWER 1 12.000 12.000 12.000 12.000
CONDENSER FAN 2 4.000 4.000 8.000 8.000
A/C POWER RELAY 1 0.060 0.060 0.060 0.060
BLOWER RELAY 1 0.060 0.060 0.060 0.060
TIME DELAY RELAY 1 0.060 0.060 0.060 0.060
EQUIPMENT QTY
CONTINUOUS
AMPS EACH
INTERMITTENT
AMPS EACH
CONTINUOUS
TOTAL
INTERMITTENT
TOTAL
POLICE EQUIPMENT
FLIR CAMERA SYSTEM 1 7.000 15.000 7.000 15.000
SEARCHLIGHT 1 40.000 50.000 40.000 50.000
SLASS ECU 1 0.135 0.385 0.135 0.385
PA/SIREN & AMPLIFIER 1 0.005 4.000 0.005 4.000
LOJACK SYSTEM 1 0.500 0.500 0.500 0.500
DVR SYSTEM 1 0.164 0.164 0.164 0.164
UC-5100 MAPPING SYSTEM 1 1.460 2.680 1.460 2.680
P-2000 X'CVR 1 1.200 4.000 1.200 4.000
MONITOR 1 1.091 1.091 1.091 1.091
