Robotiq Screwdriving Solution - Instruction Manual
3.3.Environmental and Operating Conditions
3.3.1.Robotiq Screwdriver
CONDITION VALUE
Storage / transit temperature range -20°C to 60°C
Operating ambient temperature range 0°C to 50°C
Humidity 20-80%RH, non-condensing
IPrating IP4X
Other
Dust accumulation may affect performance and shorten the time between
maintenance actions.
Free from soot or fluids.
Free from corrosive liquidsor gases.
Free from explosive liquidsor gases.
Refer to IPrating.
Table 3 - 1: Environmental and operating conditions of the Robotiq Screwdriver
Info
The input filters prevent dust particleslarger than 80 µm from getting inside the valve. Dry dust will prevent the
accumulation on filters or inside the valve. The muffler must not be blocked.
Air Supply
Compressed air must be supplied to the Screwdriver according to the technical specifications. For maintenance and other
purposes, it is recommended to install a lockout valve before connecting to the product. The air supply tubing must be connected
and disconnected to, or from, the inlet port, only when the line isdepressurized. When the line ispressurized, the safety clip must
be at all times installed on the inlet port. To protect against whipping hazards, the air supply tubing must be securely attached to
the robot arm. An air fuse should also be installed.
Depressurizing the Supply Line
In order to safely depressurize the supply line, the air supply must first be shut off. Then, if no lockout valve ispresent to
depressurize the line, the Screwdriver can be activated until the pressure isfully released.
