ROBOTIQ SD-100 - Electrical Specifications

Robotiq Screwdriving Solution - Instruction Manual
7.3.Electrical Specifications
7.3.1.Robotiq Screwdriver
ELECTRICALSPECIFICATION VALUE
Nominal supply voltage 24 VDC ±10%
Quiescent power (minimum power consumption) 1.2 W (50 mA)
Peak current (at maximum force) 2.3 A
Hot swappable Yes
Type of source DC
Suggested power supply output current 2.5 A (minimum)
Suggested power supply overcurrent protection 2.9 A (maximum)
ESD safe Yes(for robotic applications)
7.3.2.Robotiq Screw Feeder
ELECTRICALSPECIFICATION VALUE
Operating voltage 120/220 VAC to 24 VDC
Nominal Power consumption 12 W (500 mA)
Quiescent power (minimum power consumption) 1.2 W (50 mA)
ESD safe Yes(for robotic applications)
76
