Robotiq Screwdriving Solution - Instruction Manual
7.2.2. Robotiq Screw Feeder
MECHANICALSPECIFICATION
VALUE
MIN MAX
Screw diameter range
1
M2.5 (#3) M5 (#10)
Screw length
2
6 mm (¼ in) 25 mm (1 in)
Screw head height - 5 mm (3/16 in)
Screw head diameter - 10 mm (3/8 in)
Typical feed rate 20 screws/ minute
Screw chamber volume 300 CC
Grossweight 5.2 kg (11.4 lb)
Dimensions (W x D x H) 157 mm x 286 mm x 171 mm (6.18 x 11.25 x 6.73 in)
Energy Source Electricity
1. For screwsover M4 or #8, validate your use case with Robotiq’s support department.
2. For socket head screws, the minimum screw length is10 mm. Please validate with Robotiq’s support department for shorter
socket head screws.
75
