Robotiq Screwdriving Solution - Instruction Manual
4.5.Screwdriver Vacuum Sleeve Selection
The correct screwdriver bit and vacuum sleeve combination must be selected to get proper results.
Info
The following chartsonly show the maximum bit gauge size for a given sleeve.
Select the bit according to the screw specifications.
4.5.1.Self-Tapping Screws
41
