Robotiq Screwdriving Solution - Instruction Manual
l
rotation_speed=500
l
pick_speed=25
l
timeout=90
l
retract_speed=40
l
direction=RQ_DIRECTION_CCW
l
slave_id=9
rq_screw_with_force()
Performsa screwing action until the torque value is reached and with a force
applied on the screw.
Arguments:
l
operation_mode=RQ_MODE_NORMAL
l
regulation_mode=RQ_REGULATION_MODE_CURRENT_WITH_RAMP_
DOWN
l
rotation_current=torque setpoint (Nm)
l
rotation_speed
Info
Minimum value: 1 RPM
Maximum value: 500 RPM
l
rotation_angle
Info
If the regulation_mode isRQ_REGULATION_MODE_ANGLE, then
rotation_angle isthe number of degrees to rotate before the
Screwdriver stops.
Minimum value: 1
Maximum value: 240000
l
teach_thread_mating_position
l
teach_final_position
l
expected_final_position
Info
Final position reached at the end of the screwdriving action.
l
force=10
l
timeout=10
