Roche cobas b 221 system

Roche Diagnostics May 2009
Service Manual · Version 9.0 G-9
cobas b 221 system 8 Versions
Service Manual
Version 4.1
Version 5.0
Version Nr. Date of Release Modified Chapters Applicable from Software Version
4.1 July 2005 All chapters 4.02
Ta bl e G -9
Chapter–Page Modification / Addition
Cover page New: Edition notice
Cover page New: Intended use
Cover page New: Trademarks
Table of contents Update:
Preface Add: Preface
Preface Add: How to Use Manual
Preface Add: Where to Find Information
Preface Add: Conventions used in this manual
Safety information New chapter name: Chapter ’Introduction’ was changed to ’Safety information’.
Glossary New chapter:
Versions New chapter:
Version Add: Version 4.1
All chapters o Add: ’Part’ page (A - G)
o Change: Chapter structure
o Change: Paragraph style
o Update: Table of Contents
Ta b le G - 10
Version Nr. Date of Release Modified Chapters Applicable from Software Version
5.0 November 2005 see below 5.00
Ta bl e G -1 1
Part–Page Modification / Addition
Table of contents Updated
Version, Date Update: Version 5.0, November 2005
8 Invisible laser radiation: new symbol
A-15 new fluidics graphics (all instrument configurations)
A-21 Pin assignment of S2 and S3 fluid packs: numbering removed
A-22 T&D positions new
A-41 MSS standby calibration modified
B-6 Protected setup: cobas b 221 settings new
B-8 USB functionality (service logfile export) new
B16 Tubing V4 – MC cartridge: new figure
B-22 T&D tubing set: figure changed
B-32, B-47 Replacing SD and MC cartridge: new note
Ta b le G - 12
