CONTROLELEMENTS
FRONT SIDE
The ELS keyboard has buttons for operation. In addition there are 3 LEDs in the keyboard,
which are used to indicate states. In the manual, buttons are addressed with a symbol, e.g.
START, and with the following designation:
Settings
X-Axis o
Z-Axis o
LED2
Display
START
STOP-Key
LEFT
UP
(Z-STEP)
RIGHT
KNOB
DOWN
(X-STEP)
Power
ON/OFF
Zero
position
Zero Z-Axis
Zero X-Axis
SLOW JOG
X and Z axis
FAST JOG
X and Z axis
FN-KEY
Programkey/
Settings reset
Micro-SD-Card
LED3
LED1
