Rocketronics ELS 4 Basic - Setup

39
SETUP
Press the SETTINGS button to recall the settings, which are divided into several groups contain-
ing dierent items.
The structure is as shown on the left.
Navigate from group to group with LEFT and
RIGHT.
Within a group, select the elements with UP
and DOWN
The settings are exited by pressing SETTINGS
again. The settings are automatically saved.
Setup-Common
•LANGUAGE
•WAITING PERIOD
•MODE LOCK DURING SPINDLE ROTATION
•START-MODE AT SYSTEM START
•DURATION OF STEP PULSE
•X-AXIS KEYS INVERT
•MEMORYPROFILE
SETUP
ENCODER
•IMPULSES PER REV:
•REVERSE DIRECTION
SETUP
Z-MOTOR
•SPINDLE PITCH
•BACKLASH(mm)
•STEPS/REV
•ACCELERATION
•F SLOW < >
•F FAST<< >>
•REVERSE DIRECTION
SETUP
X-MOTOR
•SPINDLE PITCH
•BACKLASH(mm)
•STEPS/REV
•ACCELERATION
•F SLOW < >
•F FAST<< >>
•REVERSE DIRECTION
•AVAILABLE
SETUP
DATA
•STEP SIZE FINE
•STEP SIZE COARSE
•Z Ap FINISH:
•Z Ap ROUGH
•Z RESTPOSITION
•X Ap FINISH
•X Ap ROUGH
•X RESTPOSITION
SETUP
INPUTS
•ESTOP-INPUT ACTIVE?
•ESTOP-INPUT POLARITY
•X LIMIT ACTIVE?
•X LIMIT POLARITY
•Z LIMIT ACTIVE?
•Z LIMIT POLARITY
•ERROR ACTIVE?
•ERROR POLARIY
SETUP
OUTPUTS
•SPINDLE STOP ACTIVE?
•SPINDLE STOP SWITCH DURATION
•ESTOP-FOLLOW ACTIVE?
•ESTOP-FOLLOW DELAY
•COOL ACTIVE?
•COOL DELAY
SETUP
INFORMATION
•I/O INFORMATION INPUTS OUTPUTS
•FIRMWARE VERSION ELS 4 BASIC
•SELFTEST RESULT
