Output 3: COOL
This output is activated at the start of a cycle and can start cooling. A waiting time between ac-
tivation of cooling and start of cutting can be set in the settings. This ensures that the coolant
has reached the tool before the cut starts.
Settings -> Outputs -> COOL-OUTPUT DELAY
Output 4: AUX
Not used yet
NOTE
All outputs are deactivated at the factory and must rst be activated in the settings!
The voltage applied to OUTPOW IN is switched to the outputs. If the terminal is not con-
nected, no voltage is output at the outputs! Connect OUTPOW IN with +12V or another DC
voltage up to max. 24V.
CAUTION
Only apply DC voltage to the voltage input OUTPOW IN, otherwise the control may be
damaged.
