108 Rockwell Automation Publication KNX-SG001H-EN-P - December 2020
Kinetix 5500 Servo Drives
Kinetix VPAR Performance Specifications with Kinetix 5500 Drives
Performance Specifications with Kinetix 5500 (200V-class operation) Drives
Performance Specifications with Kinetix 5500 (400V-class operation) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient temperature and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Kinetix MPAR Performance Specifications with Kinetix 5500 Drives
These actuators require the 2198-H2DCK feedback converter kit.
Performance Specifications with Kinetix 5500 (200V-class operation) Drives
Performance Specifications with Kinetix 5500 (400V-class operation) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient temperature and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Electric Cylinder
Cat. No.
Maximum Speed
mm/s (in/s)
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak Stall
Current
A 0-pk
System Peak
Stall Force
N (lb)
Motor Output
Power Rating
kW
Kinetix 5500 Drives
(240V AC input)
VPAR-A1xxxB 150 0.88 240 (53.9) 2.90 300 (67.4) 0.11 2198-H008-ERSx
VPAR-A1xxxE 500 1.66 280 (62.9) 2.90 350 (78.7) 0.23 2198-H008-ERSx
VPAR-A2xxxC 250 1.74 420 (94.4) 3.72 525 (118) 0.25 2198-H008-ERSx
VPAR-A2xxxF 640 4.45 640 (144) 8.40 800 (180) 0.56 2198-H015-ERSx
VPAR-A3xxxE 500 12.30 2000 (450) 31.70 2500 (562) 1.30 2198-H040-ERSx
VPAR-A3xxxH 1000 13.50 1284 (289) 27.00 1625 (365) 1.56 2198-H040-ERSx
Electric Cylinder
Cat. No.
Maximum Speed
mm/s (in/s)
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak Stall
Current
A 0-pk
System Peak
Stall Force
N (lb)
Motor Output
Power Rating
kW
Kinetix 5500 Drives
(480V AC input)
VPAR-B1xxxB 150 0.41 240 (53.9) 1.34 300 (67.4) 0.11 2198-H003-ERSx
VPAR-B1xxxE 500 1.20 280 (62.9) 2.10 350 (78.7) 0.24 2198-H003-ERSx
VPAR-B2xxxC 250 1.25 420 (94.4) 2.67 525 (118) 0.25 2198-H003-ERSx
VPAR-B2xxxF 640 3.10 640 (144) 5.80 800 (180) 0.56 2198-H008-ERSx
VPAR-B3xxxE 500 5.10 2000 (450) 13.0 2500 (562) 1.30 2198-H015-ERSx
VPAR-B3xxxH 1000 8.60 1284 (289) 17.0 1625 (365) 1.68 2198-H015-ERSx
Electric Cylinder
Cat. No.
Maximum Speed
mm/s (in/s)
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak Stall
Current
A 0-pk
System Peak
Stall Force
N (lb)
Motor Output
Power Rating
kW
Kinetix 5500 Drives
(240V AC input)
MPAR-A1xxxB 150 1.15 240 (53.9) 1.35 300 (67.4) 0.036 2198-H003-ERSx
MPAR-A1xxxE 500 2.16 280 (62.9) 2.48 350 (78.7) 0.140 2198-H008-ERSx
MPAR-A2xxxC 250 2.42 420 (94.4) 2.72 525 (118) 0.105 2198-H008-ERSx
MPAR-A2xxxF 640 4.54 640 (144) 5.41 800 (180) 0.410 2198-H015-ERSx
MPAR-A3xxxE 500 10.33 2000 (450) 12.34 2500 (562) 1.00 2198-H025-ERSx
MPAR-A3xxxH 1000 12.20 1300 (292) 16.40 1625 (365) 1.30 2198-H040-ERSx
Electric Cylinder
Cat. No.
Maximum Speed
mm/s (in/s)
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak Stall
Current
A 0-pk
System Peak
Stall Force
N (lb)
Motor Output
Power Rating
kW
Kinetix 5500 Drives
(480V AC input)
MPAR-B1xxxB 150 1.15 240 (53.9) 1.35 300 (67.4) 0.036 2198-H003-ERSx
MPAR-B1xxxE 500 1.49 280 (62.9) 1.71 350 (78.7) 0.140 2198-H003-ERSx
MPAR-B2xxxC 250 1.67 420 (94.4) 1.90 525 (118) 0.105 2198-H003-ERSx
MPAR-B2xxxF 640 3.29 640 (144) 3.93 800 (180) 0.410 2198-H008-ERSx
MPAR-B3xxxE 500 5.16 2000 (450) 6.17 2500 (562) 1.00 2198-H015-ERSx
MPAR-B3xxxH 1000 6.13 1300 (292) 6.79 1625 (365) 1.30 2198-H015-ERSx
