214 Rockwell Automation Publication KNX-SG001H-EN-P - December 2020
Kinetix 300 and Kinetix 350 EtherNet/IP Servo Drives
Kinetix MPM Motor Performance Specifications with Kinetix 300/350 Drives
Performance Specifications with Kinetix 300/350 (200V-class) Drives
Performance Specifications with Kinetix 300/350 (400V-class) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient temperature, and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Kinetix MPS Motor Performance Specifications with Kinetix 300/350 Drives
Performance Specifications with Kinetix 300/350 (200V-class) Drives
Performance Specifications with Kinetix 300/350 (400V-class) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient temperature, and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Motor Cat. No.
Base Speed
rpm
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A (0-pk)
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW
Kinetix 300/350
200V-class
Three-phase Drives
MPM-A1151M 4500 5000 6000 7.65 2.3 (20.3) 30.5 6.6 (58.4) 0.90 2097-V33PR5-xx
MPM-A1152F 3000 4000 5000 11.93 4.7 (41.6) 44.8 13.5 (119) 1.40 2097-V33PR6-xx
Motor Cat. No.
Base Speed
rpm
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A (0-pk)
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW
Kinetix 300/350
400V-class
Three-phase Drives
MPM-B1151F 3000 4000 5000 2.71 2.3 (20.3) 9.9 6.6 (58.4) 0.75 2097-V34PR5-xx
MPM-B1151T 6000 5000 7000 5.62 2.3 (20.3) 20.5 5.8 (51.3) 0.90 2097-V34PR6-xx
MPM-B1152C 1500 2500 3000 3.61 5.0 (44.2) 12.4 13.5 (119) 1.20 2097-V34PR5-xx
MPM-B1152F 3000 4000 5200 6.17 5.0 (44.2) 21.1 13.3 (118) 1.40
2097-V34PR6-xx
MPM-B1153E 2250 3000 3500 6.21 6.5 (57.5) 21.6 19.7 (174) 1.40
MPM-B1302F 3000 4000 4500 8.57 6.6 (58.4) 22.0 13.2 (117) 1.65
MPM-B1304C 1500 1870 2750 7.0 10.3 (91.1) 22.3 27.1 (240) 2.00
Motor Cat. No.
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A (0-pk)
System Peak
Stall Torque
N•m (lb•in)
Motor Rated Output
kW
Kinetix 300/350
200V-class
Three-phase Drives
MPS-A330P 5000 5000 9.80 3.60 (32)
33.9 10.1 (89.4)
1.3
2097-V33PR5-xx
38.0 11.1 (98.2)
2097-V33PR6-xx
MPS-A4540F 3000 3000 14.4 8.1 (72) 50.9 24.8 (219) 1.4
Motor Cat. No.
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A (0-pk)
System Peak
Stall Torque
N•m (lb•in)
Motor Rated Output
kW
Kinetix 300/350
400V-class
Three-phase Drives
MPS-B330P 5000 5000 4.90 3.6 (32)
16.9 10.1 (89.4)
1.3
2097-V34PR5-xx
19.0 11.1 (98.2)
2097-V34PR6-xx
MPS-B4540F 3000 3000 7.1 8.1 (72) 25.4 26.3 (233) 1.4
