Kinetix 5500 Servo Drives
Kinetix VPH (non-brake) Performance Specifications with Kinetix 5500 (400V-class operation) Drives
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Kinetix VPH (brake) Performance Specifications with Kinetix 5500 (400V-class operation) Drives
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Kinetix VPS Motor Performance Specifications with Kinetix 5500 Drives
Performance Specifications with Kinetix 5500 (400V-class operation) Drives
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Motor Cat. No.
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW (Hp)
Kinetix 5500 Drives
(480V AC input)
VPH-B0632T-xxx2 8000 8000 2.44 0.84 (7.5) 8.75 2.69 (24.0) 0.52 (0.69) 2198-H008-ERSx
VPH-B0633M-xxx2 6700 6700 2.05 1.03 (9.2) 8.75 4.09 (36.0) 0.50 (0.67) 2198-H008-ERSx
VPH-B0753F-xxx2 6600 6600 3.68 1.87 (16.6)
17.70 6.57 (58.0)
0.74 (0.99)
2198-H015-ERSx
18.90 7.02 (62.0) 2198-H025-ERSx
VPH-B1001F-xxx2 5000 5000 2.19 1.44 (12.8) 7.10 3.61 (32.0) 0.70 (0.93) 2198-H008-ERSx
VPH-B1003F-xxx2 4750 4750 4.93 3.43 (30.4)
17.70 9.77 (86.0)
1.36 (1.83)
2198-H015-ERSx
20.20 11.15 (99.0) 2198-H025-ERSx
VPH-B1152F-xxx2 4500 4500 5.15 4.03 (35.7)
17.70 10.95 (97.0)
1.37 (1.84)
2198-H015-ERSx
21.19 13.12 (116) 2198-H025-ERSx
VPH-B1153E-xxx2 3900 5000 7.09 5.13 (45.4)
17.70 10.90 (97.0)
1.27 (1.70)
2198-H015-ERSx
33.00 20.33 (180) 2198-H040-ERSx
VPH-B1304E-xxx2 3500 3500 8.10 8.41 (74.5)
28.30 23.82 (211)
2.15 (2.88)
2198-H025-ERSx
33.76 28.45 (252) 2198-H040-ERSx
VPH-B1653D-xxx2 3000 3000 14.72 18.67 (165)
45.90 45.77 (405)
3.16 (4.23)
2198-H040-ERSx
68.0 67.80 (600) 2198-H070-ERSx
Motor Cat. No.
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW (Hp)
Kinetix 5500 Drives
(480V AC input)
VPH-B0632T-xxx4 7200 8000 2.43 0.80 (7.1) 8.75 2.69 (24.0) 0.40 (0.54) 2198-H008-ERSx
VPH-B0633M-xxx4 6700 6700 1.97 1.01 (9.0) 8.75 4.09 (36.0) 0.50 (0.67) 2198-H008-ERSx
VPH-B0753F-xxx4 6600 6600 3.49 1.81 (16.0)
8.80 3.27 (29.0)
0.68 (0.92)
2198-H008-ERSx
18.90 7.02 (62.0) 2198-H025-ERSx
VPH-B1001F-xxx4 5000 5000 2.20 1.42 (12.6) 7.10 3.61 (32.0) 0.68 (0.91) 2198-H008-ERSx
VPH-B1003F-xxx4 4750 4750 4.89 3.29 (29.1)
17.70 9.77 (86.0)
1.16 (1.56)
2198-H015-ERSx
20.20 11.15 (99.0) 2198-H025-ERSx
VPH-B1152F-xxx4 4500 4500 5.15 4.03 (35.7)
17.70 10.95 (97.0)
1.37 (1.84)
2198-H015-ERSx
21.19 13.12 (116) 2198-H025-ERSx
VPH-B1153E-xxx4 3900 5000 7.05 5.13 (45.4)
17.70 10.90 (97.0)
1.08 (1.45)
2198-H015-ERSx
33.00 20.33 (180) 2198-H040-ERSx
VPH-B1304E-xxx4 3500 3500 8.27 8.24 (73.0)
28.30 23.82 (211)
1.76 (2.36)
2198-H025-ERSx
33.76 28.45 (252) 2198-H040-ERSx
VPH-B1653D-xxx4 3000 3000 14.92 18.67 (165)
45.90 45.77 (405)
2.91 (3.91)
2198-H025-ERSx
68.00 67.80 (600) 2198-H070-ERSx
Motor Cat. No.
Rated Speed
rpm
Maximum Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW (Hp)
Kinetix 5500 Drives
(480V AC input)
VPS-B1304D 3000 3000 7.1 8.1 (72.0)
17.7 17.9 (158)
1.40 (1.9)
2198-H015-ERSx
26.0 27.1 (240) 2198-H025-ERS
x
VPS-B1653D 3000 3000 17.0 21.0 (186)
45.9 50.1 (443)
3.29 (4.4)
2198-H040-ERSx
68.0 67.8 (600) 2198-H070-ERSx
