Kinetix 6000 Multi-axis Servo Drives
LDC-Series Performance Specifications with Kinetix 6000 Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 50 °C (122 °F) ambient temperature and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Performance Specifications with Kinetix 6000 (200V-class) Drives
Linear Motor Cat. No.
Maximum Speed
m/s (ft/s)
System Continuous
Stall Current
(1)
A 0-pk
(1) Values represent the range between no cooling (low value) and water cooling (high value).
System Continuous
Stall Force
(1)
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Linear Motor
Rated Output
kW
Kinetix 6000
200V-class Drives
LDC-C030100-DHT
10.0 (32.8)
4.1…6.1 74…111 (17…25) 12.1 188 (42) 0.37…0.55 2094-AM01-S
LDC-C030200-DHT 8.1…12.2
148…222 (33…50)
24.3
375 (84) 0.74…1.11
2094-AM02-S
LDC-C030200-EHT 4.1…6.1 12.1 2094-AM01-S
LDC-C050100-DHT
10.0 (32.8)
3.9…5.9 119…179 (27…40) 11.7 302 (68) 0.59…0.89 2094-AM01-S
LDC-C050200-DHT 7.9…11.8
240…359 (54…81)
23.3
600 (135) 1.20…1.79
2094-AM02-S
LDC-C050200-EHT 3.9…5.9 11.6 2094-AMP5-S
LDC-C050300-DHT 11.8…17.7
363…544 (82…122)
35.9
941 (212) 1.81…2.72
2094-AM03-S
LDC-C050300-EHT 3.9…5.9 12.0 2094-AMP5-S
LDC-C075200-DHT
10.0 (32.8)
7.7…11.5
348…523 (78…117)
22.9
882 (198) 1.74…2.61
2094-AM02-S
LDC-C075200-EHT 3.8…5.7 11.5 2094-AMP5-S
LDC-C075300-DHT 11.5…17.2
523…784 (117…176)
35.6
1368 (308) 2.61…3.92
2094-AM03-S
LDC-C075300-EHT 3.8…5.7 11.9 2094-AM01-S
LDC-C075400-DHT 15.3…23.0
697…1045 (157…235)
47.4
1824 (410) 3.48…5.22
2094-AM03-S
LDC-C075400-EHT 7.7…11.5 23.7 2094-AM02-S
LDC-C100300-DHT
10.0 (32.8)
11.1…16.7
674…1012 (152…227)
34.3
1767 (397) 3.37…5.06
2094-AM03-S
LDC-C100300-EHT 3.7…5.6 11.4 2094-AM01-S
LDC-C100400-DHT 14.8…22.2
899…1349 (202…303)
45.7
2356 (530) 4.49…6.74
2094-AM03-S
LDC-C100400-EHT 7.4…11.1 22.8 2094-AM02-S
LDC-C100600-DHT 22.2…33.3 1349…2023 (303…455) 68.5 3534 (794) 6.74…10.11 2094-AM05-S
LDC-C150400-DHT
10.0 (32.8)
14.1…21.1 1281…1922 (288…432) 45.2 3498 (786) 6.40…9.61 2094-AM03-S
LDC-C150600-DHT 21.1…31.7 1922…2882 (432…648) 67.8 5246 (1179) 9.61…14.41 2094-AM05-S
Performance Specifications with Kinetix 6000 (400V-class) Drives
Linear Motor Cat. No.
Maximum Speed
m/s (ft/s)
System Continuous
Stall Current
(1)
A 0-pk
System Continuous
Stall Force
(1)
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Linear Motor
Rated Output
kW
Kinetix 6000
400V-class Drives
LDC-C030100-DHT
10.0 (32.8)
4.1…6.1 74…111 (17…25) 12.1 188 (42) 0.37…0.55 2094-BM01-S @ 150%
LDC-C030200-DHT 8.1…12.2
148…222 (33…50)
24.3
375 (84) 0.74…1.11
2094-BM02-S @ 250%
LDC-C030200-EHT 4.1…6.1 12.1 2094-BM01-S @ 150%
LDC-C050100-DHT
10.0 (32.8)
3.9…5.9 119…179 (27…40) 11.7 302 (68) 0.59…0.89 2094-BM01-S @ 150%
LDC-C050200-DHT 7.9…11.8
240…359 (54…81)
23.3
600 (135) 1.20…1.79
2094-BM02-S @ 250%
LDC-C050200-EHT 3.9…5.9 11.6 2094-BM01-S @ 150%
LDC-C050300-DHT 11.8…17.7
363…544 (82…122)
35.9
941 (212) 1.81…2.72
2094-BM02-S @ 250%
LDC-C050300-EHT 3.9…5.9 12.0 2094-BM01-S @ 150%
LDC-C075200-DHT
10.0 (32.8)
7.7…11.5
348…523 (78…117)
22.9
882 (198) 1.74…2.61
2094-BM02-S @ 250%
LDC-C075200-EHT 3.8…5.7 11.5 2094-BM01-S @ 150%
LDC-C075300-DHT 11.5…17.2
523…784 (117…176)
35.6
1368 (308) 2.61…3.92
2094-BM02-S @ 250%
LDC-C075300-EHT 3.8…5.7 11.9 2094-BM01-S @ 150%
LDC-C075400-DHT 15.3…23.0
697…1045 (157…235)
47.4
1824 (410) 3.48…5.22
2094-BM03-S @ 250%
LDC-C075400-EHT 7.7…11.5 23.7
2094-BM02-S @ 250%
LDC-C100300-DHT
10.0 (32.8)
11.1…16.7
674…1012 (152…227)
34.3
1767 (397) 3.37…5.06
LDC-C100300-EHT 3.7…5.6 11.4 2094-BM01-S @ 150%
LDC-C100400-DHT 14.8…22.2
899…1349 (202…303)
45.7
2356 (530) 4.49…6.74
2094-BM03-S @ 250%
LDC-C100400-EHT 7.4…11.1 22.8 2094-BM02-S @ 250%
LDC-C100600-DHT 22.2…33.3
1349…2023 (303…455)
68.5
3534 (794) 6.74…10.11
2094-BM03-S @ 250%
LDC-C100600-EHT 11.1…16.7 34.3 2094-BM02-S @ 250%
