Rockwell Automation Publication KNX-SG001H-EN-P - December 2020 99
Kinetix 5500 Servo Drives
Performance Specifications with Kinetix 5500 (400V-class operation) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient temperature and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Kinetix MPS Motor Performance Specifications with Kinetix 5500 Drives
These motors require the 2198-H2DCK feedback converter kit.
Kinetix MPS Motor Performance Specifications with Kinetix 5500 (200V-class operation) Drives
Kinetix MPS Motor Performance Specifications with Kinetix 5500 (400V-class operation) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient temperature and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Motor Cat. No.
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated Output
kW
Kinetix 5500 Drives
(480V AC input)
MPF-B310P 5000 5000 2.30 1.60 (14) 7.10 3.6 (32) 0.77 2198-H008-ERSx
MPF-B320P 5000 5000 4.24 3.10 (27) 14.0 7.8 (69) 1.5 2198-H015-ERSx
MPF-B330P 5000 5000 5.70 4.18 (37)
17.7 10.4 (92.0)
1.6
2198-H015-ERSx
19.0 11.1 (98) 2198-H025-ERSx
MPF-B430P 5000 5000 9.20 6.55 (58)
28.3 17.6 (156)
2.0
2198-H025-ERSx
32.0 19.8 (175) 2198-H040-ERSx
MPF-B4530K 4000 4000 9.90 8.25 (73)
28.3 18.7 (165)
2.4
2198-H025-ERSx
31.0 20.3 (179) 2198-H040-ERSx
MPF-B4540F 3000 3000 9.10 10.20 (90)
28.3 26.2 (232)
2.5
2198-H025-ERSx
29.0 27.1 (240) 2198-H040-ERSx
MPF-B540K 4000 4000 20.5 19.4 (171) 60.0 48.6 (430) 4.1 2198-H070-ERSx
Motor Cat. No.
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated Output
kW
Kinetix 5500 Drives
(240V AC input)
MPS-A330P 5000 5000 9.80 3.60 (32.0)
28.3 8.79 (77.8)
1.3
2198-H025-ERSx
38.0 11.10 (98.2) 2198-H040-ERSx
MPS-A4540F 3000 3000 14.4 8.1 (72)
45.9 22.84 (202)
1.4
2198-H040-ERSx
56.0 27.1 (240) 2198-H070-ERSx
Motor Cat. No.
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated Output
kW
Kinetix 5500 Drives
(480V AC input)
MPS-B330P 5000 5000 4.9 3.60 (32)
17.7 10.5 (92.9)
1.3
2198-H015-ERSx
19.0 11.0 (97.2) 2198-H025-ERSx
MPS-B4540F 3000 3000 7.1 8.1 (72)
17.7 19.2 (170)
1.4
2198-H015-ERSx
26.0 27.1 (240) 2198-H025-ERSx
MPS-B560F 3000 3000 17.0 21.5 (190)
45.9 49.7 (440)
3.5
2198-H040-ERSx
68.0 67.8 (600) 2198-H070-ERSx
