Kinetix 5100 EtherNet/IP Indexing Servo Drives
Kinetix TLP Motor Performance Specifications with Kinetix 5100 Drives
Performance Specifications with Kinetix 5100 (200V-class) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor ambient at 40 °C (104 °F), drive ambient at 50 °C (122 °F), and rated line voltage.
For additional information on ambient and line conditions, refer to Motion Analyzer.
Performance Specifications with Kinetix 5100 (400V-class) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor ambient at 40 °C (104 °F), drive ambient at 50 °C (122 °F), and rated line voltage.
For additional information on ambient and line conditions, refer to Motion Analyzer.
Rotary Motor
Cat. No.
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A rms
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A rms
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW (Hp)
Kinetix 5100 Drives
(230V AC input)
TLP-A046-005 3000 6000 0.70 0.16 (1.42) 2.286 0.447 (3.96) 0.05 (0.067) 2198-E1004-ERS
TLP-A046-010 3000 6000 0.96 0.32 (2.83) 3.370 1.034 (9.15) 0.10 (0.134) 2198-E1004-ERS
TLP-A070-020 3000 6000 1.65 0.64 (5.66) 5.500 2.160 (19.12) 0.20 (0.268) 2198-E1004-ERS
TLP-A070-040 3000 6000
2.60 1.22 (10.8) 6.500 2.91 (25.80) 0.38 (0.509) 2198-E1004-ERS
2.70 1.27 (11.2) 9.500 4.275 (37.84) 0.40 (0.536) 2198-E1007-ERS
TLP-A090-075 3000 6000 4.50 2.39 (21.2) 15.41 7.505 (66.42) 0.75 (1.005) 2198-E1007-ERS
TLP-A100-100 3000 3000 4.31 3.18 (28.2) 12.37 8.740 (77.36) 1.0 (1.34)
2198-E1007-ERS
2198-E1015-ERS
TLP-A115-100 3000 5000 7.45 3.18 (28.2) 23.70 8.455 (74.83) 1.0 (1.34) 2198-E1015-ERS
TLP-A115-200 3000 5000 12.50 6.37 (56.4) 40.58 17.48 (154.7) 2.0 (2.68) 2198-E1020-ERS
TLP-A145-050 2000 3000 3.26 2.39 (21.6) 9.180 6.81 (60.27) 0.50 (0.670) 2198-E1007-ERS
TLP-A145-090 1000 2000
7.90 8.30 (73.5)
21.80 20.52 (181.6)
0.87 (1.167) 2198-E1015-ERS
8.12 8.59 (76.0) 0.90 (1.206) 2198-E1020-ERS
TLP-A145-100 2000 3000 6.11 4.77 (42.2) 19.73 13.30 (117.7) 1.0 (1.34) 2198-E1015-ERS
TLP-A145-150 2000 3000
7.90 6.22 (55.1) 23.70 15.92 (140.9) 1.3 (1.74) 2198-E1015-ERS
8.80 7.16 (63.4) 29.13 19.66 (174.0) 1.5 (2.01) 2198-E1020-ERS
TLP-A145-250 3000 4500 15.32 7.96 (70.5) 55.95 24.51 (216.9) 2.5 (3.35) 2198-E2030-ERS
TLP-A200-200 2000 3000 12.30 9.55 (84.3) 33.66 21.85 (193.4) 2.0 (2.68) 2198-E1020-ERS
TLP-A200-300 1500 2500
17.90 16.81 (148.8) 55.95 45.62 (403.7) 2.6 (3.49) 2198-E2030-ERS
20.25 19.10 (169.1) 57.50 47.03 (416.3) 3.0 (4.02) 2198-E2055-ERS
TLP-A200-350 2000 3000 22.16 16.71 (147.9) 65.40 43.23 (382.6) 3.5 (4.69) 2198-E2055-ERS
TLP-A200-450 1500 3000 37.07 28.65 (253.6) 91.40 64.04 (566.8) 4.5 (6.03) 2198-E2055-ERS
TLP-A200-550 1500 3000 41.13 35.01 (309.9)
91.40 67.67 (598.9)
5.5 (7.37)
2198-E2055-ERS
108.0 79.96 (707.7) 2198-E2075-ERS
TLP-A200-750 1500 2500
49.0 45.36 (401.4)
127.5 104.30 (923.1)
7.1 (9.52) 2198-E2075-ERS
49.80 47.74 (422.5) 7.5 (10.1) 2198-E2150-ERS
TLP-A235-11K 1500 2000 57.72 70.0 (619.6) 129.5 144.30 (1277) 11.0 (14.7) 2198-E2150-ERS
TLP-A235-15K 1500 2000 75.40 95.40 (844.4) 162.0 184.57 (1634) 15.0 (20.1) 2198-E2150-ERS
Rotary Motor
Cat. No.
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A rms
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A rms
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW (Hp)
Kinetix 5100 Drives
(380/480V AC input)
TLP-B070-040 3000 6000 1.47 1.27 (11.2) 5.30 4.25 (37.6) 0.40 (0.54) 2198-E4004-ERS
TLP-B090-075 3000 6000 2.99 2.39 (21.2) 10.85 8.05 (71.2) 0.75 (1.01) 2198-E4015-ERS
TLP-B115-100 3000 5000 4.30 3.18 (28.1) 15.11 9.34 (82.6) 1.0 (1.34) 2198-E4015-ERS
TLP-B115-200 3000 5000 7.0 6.37 (56.4) 25.40 19.10 (169.0) 2.0 (2.68) 2198-E4030-ERS
TLP-B145-050 2000 3000 1.89 2.39 (21.2) 5.49 6.93 (61.3) 0.50 (0.67) 2198-E4007-ERS
TLP-B145-100 2000 3000 3.54 4.77 (42.4) 12.29 13.03 (115.3) 1.0 (1.34) 2198-E4015-ERS
TLP-B145-150 2000 3000 5.20 7.16 (63.4) 18.34 20.54 (181.8) 1.5 (2.01) 2198-E4020-ERS
TLP-B145-200 2000 3000 6.85 9.55 (84.5) 21.35 24.40 (216.0) 2.0 (2.68) 2198-E4020-ERS
TLP-B145-250 3000 4500 8.60 7.96 (70.5) 33.40 26.30 (232.8) 2.5 (3.35) 2198-E4055-ERS
TLP-B200-300 1500 2500 11.65 19.1 (169.0) 34.10 47.8 (423.0) 3.0 (4.02) 2198-E4030-ERS
TLP-B200-450 1500 3000 21.18 28.7 (254.0) 58.41 67.6 (598.0) 4.5 (6.03) 2198-E4075-ERS
TLP-B200-550 1500 3000 23.62 35.0 (310.0) 66.60 83.8 (742.0) 5.5 (7.38) 2198-E4075-ERS
TLP-B200-750 1500 2500 28.90 47.7 (422.0) 70.0 101.3 (896.0) 7.5 (10.1) 2198-E4150-ERS
TLP-B235-11K 1500 2000 29.60 70.0 (620.0) 70.0 158.5 (1403) 11.0 (14.8) 2198-E4150-ERS
TLP-B235-14K 1500 2000 40.30 89.1 (789.0) 70.0 143.6 (1271) 14.0 (18.8) 2198-E4150-ERS
