Kinetix 5300 Single-axis EtherNet/IP Servo Drives
Kinetix MPAS Performance Specifications with Kinetix 5300 Drives
Performance Specifications with Kinetix 5300 (200V-class) Drives
Performance Specifications with Kinetix 5300 (400V-class) Drives
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Kinetix MPAR Performance Specifications with Kinetix 5300 Drives
Performance Specifications with Kinetix 5300 (200V-class) Drives
Performance Specifications with Kinetix 5300 (400V-class) Drives
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Linear Stage
Cat. No.
Maximum Speed
mm/s (in/s)
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak Stall
Current
A 0-pk
System Peak Stall
Force
N (lb)
Motor Output
Power Rating
kW
Kinetix 5300 Drives
(230V AC input)
MPAS-Axxxx1-V05SxA
200 (7.9)
(1)
(1) For 900 mm stroke length, maximum speed is 176 mm/s (6.9 in/s). For 1020 mm stroke length, maximum speed is 143 mm/s (5.6 in/s).
3.09 521 (117) 6.10 1212 (272) 0.37 2198-C1004-ERS
MPAS-Axxxx2-V20SxA
1124 (44.3)
(2)
(2) For 780 mm stroke length, maximum speed is 889 mm/s (35.0 in/s). For 900 mm stroke length, maximum speed is 715 mm/s (28.2 in/s). For 1020 mm stroke length, maximum speed is
582 mm/s (22.9 in/s).
4.54 462 (104) 9.10 968 (218) 0.62 2198-C1007-ERS
MPAS-A6xxxB-ALMO2C
5000 (200)
5.3 105 (23.6) 15.8 359 (80.7) 0.32
2198-C1007-ERS
MPAS-A6xxxB-ALMS2C 4.7 83.0 (18.7) 14.2 312 (70.1) 0.29
MPAS-A8xxxE-ALMO2C 7.0 189 (42.5) 18.5 456 (103) 0.53 2198-C1015-ERS
MPAS-A8xxxE-ALMS2C 6.3 159 (35.7) 16.7 399 (89.7) 0.48 2198-C1007-ERS
MPAS-A9xxxK-ALMO2C 6.7 285 (64.1) 18.3 680 (153) 0.77 2198-C1015-ERS
MPAS-A9xxxK-ALMS2C 6.1 245 (55.1) 16.5 601 (135) 0.69 2198-C1007-ERS
Linear Stage
Cat. No.
Maximum Speed
mm/s (in/s)
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak Stall
Current
A 0-pk
System Peak Stall
Force
N (lb)
Motor Output
Power Rating
kW
Kinetix 5300 Drives
(480V AC input)
MPAS-Bxxxx1-V05SxA
200 (7.9)
(1)
(1) For 900 mm stroke length, maximum speed is 176 mm/s (6.9 in/s). For 1020 mm stroke length, maximum speed is 143 mm/s (5.6 in/s).
1.75 521 (117) 3.50 1212 (272) 0.37 2198-C4004-ERS
MPAS-Bxxxx2-V20SxA
1124 (44.3)
(2)
(2) For 780 mm stroke length, maximum speed is 889 mm/s (35.0 in/s). For 900 mm stroke length, maximum speed is 715 mm/s (28.2 in/s). For 1020 mm stroke length, maximum speed is
582 mm/s (22.9 in/s).
3.30 462 (104) 6.60 968 (218) 0.62 2198-C4007-ERS
MPAS-B8xxxF-ALMO2C 5000 (200) 3.50 189 (42.5) 9.30 456 (103) 0.527
2198-C4007-ERS
MPAS-B8xxxF-ALMS2C 5000 (200) 3.15 159 (35.7) 8.37 399 (89.7) 0.475
MPAS-B9xxxL-ALMO2C 5000 (200) 3.40 285 (64.1) 9.10 680 (153) 0.768
MPAS-B9xxxL-ALMS2C 5000 (200) 3.03 245 (55.1) 8.19 601 (135) 0.69
Electric Cylinder
Cat. No.
Maximum Speed
mm/s (in/s)
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Motor Output Power
Rating
kW
Kinetix 5300 Drives
(230V AC input)
MPAR-A1xxxB 150 1.15 240 (53.9) 1.35 300 (67.4) 0.036 2198-C1004-ERS
MPAR-A1xxxE 500 2.16 280 (62.9) 2.48 350 (78.7) 0.140 2198-C1004-ERS
MPAR-A2xxxC 250 2.42 420 (94.4) 2.72 525 (118) 0.105 2198-C1004-ERS
MPAR-A2xxxF 640 4.54 640 (144) 5.41 800 (180) 0.410 2198-C1007-ERS
MPAR-A3xxxE 500 10.33 2000 (450) 12.34 2500 (562) 1.00 2198-C1015-ERS
MPAR-A3xxxH 1000 12.20 1300 (292) 16.40 1625 (365) 1.30 2198-C1020-ERS
Electric Cylinder
Cat. No.
Maximum Speed
mm/s (in/s)
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak Stall
Current
A 0-pk
System Peak Stall
Force
N (lb)
Motor Output Power
Rating
kW
Kinetix 5300 Drives
(480V AC input)
MPAR-B1xxxB 150 1.15 240 (53.9) 1.35 300 (67.4) 0.036 2198-C4004-ERS
MPAR-B1xxxE 500 1.49 280 (62.9) 1.71 350 (78.7) 0.140 2198-C4004-ERS
MPAR-B2xxxC 250 1.67 420 (94.4) 1.90 525 (118) 0.105 2198-C4004-ERS
MPAR-B2xxxF 640 3.29 640 (144) 3.93 800 (180) 0.410 2198-C4007-ERS
MPAR-B3xxxE 500 5.16 2000 (450) 6.17 2500 (562) 1.00 2198-C4015-ERS
MPAR-B3xxxH 1000 6.13 1300 (292) 6.79 1625 (365) 1.30 2198-C4015-ERS
