224 Rockwell Automation Publication KNX-SG001H-EN-P - December 2020
Kinetix 300 and Kinetix 350 EtherNet/IP Servo Drives
Kinetix MPAR Performance Specifications with Kinetix 300/350 Drives
Performance Specifications with Kinetix 300/350 (200V-class, single-phase) Drives
Performance Specifications with Kinetix 300/350 (200V-class, three-phase) Drives
Performance Specifications with Kinetix 300/350 (400V-class, three-phase) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient temperature, and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Electric Cylinder
Cat. No.
Maximum Speed
mm/s (in/s)
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Motor Output
Power Rating
kW
Kinetix 300/350
400V-class
Single-phase Drives
MPAR-A1xxxB 150 1.15 240 (53.9) 1.35 300 (67.4) 0.036
2097-V33PR1-xx
2097-V32PR0-xx
2097-V31PR0-xx
MPAR-A1xxxE 500 2.16 280 (62.9) 2.48 350 (78.7) 0.140
MPAR-A2xxxC 250 2.42 420 (94.4) 2.72 525 (118) 0.105
MPAR-A2xxxF 640 4.54 640 (144) 5.41 800 (180) 0.410
2097-V33PR3-xx
2097-V32PR2-xx
2097-V31PR2-xx
MPAR-A3xxxE 500 10.33 2000 (450) 12.34 2500 (562) 1.00
2097-V33PR5-xx
2097-V32PR4-xx
Electric Cylinder
Cat. No.
Maximum Speed
mm/s (in/s)
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Motor Output
Power Rating
kW
Kinetix 300/350
200V-class
Three-phase Drives
MPAR-A1xxxB 150 1.15 240 (53.9) 1.35 300 (67.4) 0.036
2097-V33PR1-xxMPAR-A1xxxE 500 2.16 280 (62.9) 2.48 350 (78.7) 0.140
MPAR-A2xxxC 250 2.42 420 (94.4) 2.72 525 (118) 0.105
MPAR-A2xxxF 640 4.54 640 (144) 5.41 800 (180) 0.410 2097-V33PR3-xx
MPAR-A3xxxE 500 10.33 2000 (450) 12.34 2500 (562) 1.00 2097-V33PR5-xx
MPAR-A3xxxH 1000 12.20 1300 (292) 16.40 1625 (365) 1.30 2097-V33PR6-xx
Electric Cylinder
Cat. No.
Maximum Speed
mm/s (in/s)
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Motor Output
Power Rating
kW
Kinetix 300/350
400V-class
Three-phase Drives
MPAR-B1xxxB 150 1.15 240 (53.9) 1.35 300 (67.4) 0.036
2097-V34PR3-xxMPAR-B1xxxE 500 1.49 280 (62.9) 1.71 350 (78.7) 0.140
MPAR-B2xxxC 250 1.67 420 (94.4) 1.90 525 (118) 0.105
MPAR-B2xxxF 640 3.29 640 (144) 3.93 800 (180) 0.410
2097-V34PR5-xx
MPAR-B3xxxE 500 5.16 2000 (450) 6.17 2500 (562) 1.00
MPAR-B3xxxH 1000 6.13 1300 (292) 6.79 1625 (365) 1.30 2097-V34PR6-xx
