Kinetix 5700 Servo Drives
Linear Motion Performance Specifications
These linear motion families are compatible with Kinetix 5700 servo drives.
For Kinetix 5700 drive system combinations that include cable catalog number selection and force/velocity curves, refer to the Kinetix 5700
Drive Systems Design Guide, publication KNX-RM010
.
LDAT-Series Performance Specifications with Kinetix 5700 Drives
Performance Specifications with Frame 30 Linear Thrusters
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Linear Motion Family Page
LDAT-Series integrated linear thrusters 68
Kinetix MPAS integrated linear stages 72
Kinetix VPAR electric cylinders 72
Kinetix MPAR electric cylinders 73
LDC-Series linear motors 73
Kinetix MPAI heavy-duty electric cylinders 74
IMPORTANTIMPORTANT These system combinations do not include all possible motor/drive combinations. Refer to Motion Analyzer to verify
compatibility. To access Motion Analyzer, go to: https://motionanalyzer.rockwellautomation.com
.
Linear Thruster
Cat. No.
Velocity, max
460V AC
m/s
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Rated Output
460V AC
kW
Kinetix 5700 Drives
(480V AC input)
LDAT-S031010-Dxx 2.4
4.8 81 (18) 12.2 168 (38)
0.20
2198-D012-ERSx
LDAT-S031020-Dxx 3.1 0.25
LDAT-S031030-Dxx 3.5 0.29
LDAT-S031040-Dxx 3.8 0.31
LDAT-S032010-Dxx 3.1
7.4
126 (28)
24.3
336 (76)
0.40
2198-D020-ERSx
LDAT-S032020-Dxx 4.1 0.52
LDAT-S032030-Dxx 4.7 0.59
LDAT-S032040-Dxx 5.0 0.63
LDAT-S032010-Exx 3.1
3.7 12.2
0.40
2198-D012-ERSx
LDAT-S032020-Exx 4.1 0.52
LDAT-S032030-Exx 4.7 0.59
LDAT-S032040-Exx 5.0 0.63
LDAT-S033010-Dxx 3.5
11.1
190 (43)
36.5
504 (113)
0.67
2198-D032-ERSx
LDAT-S033020-Dxx 4.7 0.88
LDAT-S033030-Dxx
5.0 0.95
LDAT-S033040-D
xx
LDAT-S033010-Exx 3.5
3.7 12.2
0.67
2198-D012-ERSx
LDAT-S033020-Exx 4.7 0.87
LDAT-S033030-Exx
5.0 0.91
LDAT-S033040-Exx
