Rockwell Automation Publication KNX-SG001H-EN-P - December 2020 69
Kinetix 5700 Servo Drives
Performance Specifications with Frame 50 Linear Thrusters
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Linear Thruster
Cat. No.
Velocity, max
460V AC
m/s
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Rated Output
460V AC
kW
Kinetix 5700 Drives
(480V AC input)
LDAT-S051010-Dxx 2.8
3.1 119 (27) 11.4 363 (82)
0.34
2198-D012-ERSx
LDAT-S051020-Dxx 3.7 0.43
LDAT-S051030-Dxx 4.1 0.49
LDAT-S051040-Dxx 4.4 0.53
LDAT-S051050-Dxx 4.7 0.55
LDAT-S052010-Dxx 3.7
6.2
251 (56)
22.7
727 (163)
0.92
2198-D020-ERSx
LDAT-S052020-Dxx 4.8 1.20
LDAT-S052030-Dxx
5.0 1.24LDAT-S052040-Dxx
LDAT-S052050-Dxx
LDAT-S052010-Exx 3.7
3.1 11.4
0.80
2198-D012-ERSx
LDAT-S052020-Exx 4.6 0.98
LDAT-S052030-Exx
4.6 1.02LDAT-S052040-Exx
LDAT-S052050-Exx
LDAT-S053010-Dxx 4.1
9.4
378 (85)
34.2
1093 (246)
1.56
2198-D032-ERSx
LDAT-S053020-Dxx
5.0 1.87
LDAT-S053030-Dxx
…
LDAT-S053050-Dxx
LDAT-S053010-Exx
…
LDAT-S053050-Exx
3.5 3.1 11.4 1.04 2198-D012-ERSx
LDAT-S054010-Dxx 4.4
12.4
509 (114)
45.5
1453 (327)
2.26
2198-D032-ERSx
LDAT-S054020-Dxx
…
LDAT-S054050-Dxx
5.00 2.53
LDAT-S054010-Exx 4.4
6.2 22.7
1.87
2198-D020-ERSx
LDAT-S054020-Exx
…
LDAT-S054050-Exx
5.0 2.05
