136 Rockwell Automation Publication KNX-SG001H-EN-P - December 2020
Kinetix 5300 Single-axis EtherNet/IP Servo Drives
Kinetix MPAI Performance Specifications with Kinetix 5300 (400V-class) Drives
Performance Specifications with (ballscrew) Electric Cylinders
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Performance Specifications with (roller screw) Electric Cylinders
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Electric Cylinder
Cat. No.
Maximum
Speed
mm/s (in/s)
System Continuous
Stall Current
A 0-pk
System Continuous Stall Force
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Motor Output
Power Rating
kW
Kinetix 5300 Drives
(480V AC input)
25 °C (77 °F) 40 °C (104 °F)
MPAI-B2076CV1
305 (12)
0.90 890 (200) 706 (159) 2.30
1446 (325)
0.22
2198-C4004-ERS
MPAI-B2150CV3
1.29 1446 (325) 1147 (258) 3.25 0.25
MPAI-B2300CV3
MPAI-B3076CM1 305 (12)
1.35
1624 (365) 1290 (290)
4.57
4448 (1000)
0.27
MPAI-B3076EM1 610 (24) 814 (183) 645 (145) 2570 (578)
MPAI-B3150CM3
279 (11)
2.81
4003 (900) 3176 (714) 4.30 4448 (1000)
0.39 2198-C4007-ERS
MPAI-B3300CM3
MPAI-B3450CM3 188 (7.3)
MPAI-B3150EM3
559 (22)
2002 (450) 1588 (357) 7.07 4003 (900)MPAI-B3300EM3
MPAI-B3450EM3 376 (15)
MPAI-B4150CM3
279 (11)
5.61
7784 (1750) 6179 (1389) 8.68 8896 (2000)
0.43 2198-C4015-ERS
MPAI-B4300CM3
MPAI-B4450CM3 245 (9.5)
MPAI-B4150EM3
559 (22)
3892 (875) 3092 (695) 14.14 7784 (1750)MPAI-B4300EM3
MPAI-B4450EM3 491 (19)
MPAI-B5xxxCM3 200 (7.8)
6.62
13,123 (2950) 10,415 (2341) 8.48 13,345 (3000)
0.55 2198-C4015-ERS
MPAI-B5xxxEM3 400 (15.6) 6562 (1475) 5208 (1171) 16.70 13,122 (2950)
Electric Cylinder
Cat. No.
Maximum
Speed
mm/s (in/s)
System Continuous
Stall Current
A 0-pk
System Continuous Stall Force
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Motor Output
Power Rating
kW
Kinetix 5300 Drives
(480V AC input)
25 °C (77 °F) 40 °C (104 °F)
MPAI-B3076RM1 305 (12)
1.45
1557 (350) 1237 (278)
4.57
4862 (1093)
0.27 2198-C4004-ERS
MPAI-B3076SM1 610 (24) 778 (175) 618 (139) 2431 (547)
MPAI-B3150RM3
279 (11)
2.81
3781 (850) 3003 (675)
7.07
7562 (1700)
0.39 2198-C4007-ERS
MPAI-B3300RM3
MPAI-B3450RM3 176 (6.9)
MPAI-B3150SM3
559 (22)
1891 (425) 1499 (337) 3781 (850)MPAI-B3300SM3
MPAI-B3450SM3 353 (14)
MPAI-B4150RM3
279 (11)
5.61
7340 (1650) 5827 (1310)
14.14
14,679 (3300)
0.43 2198-C4015-ERS
MPAI-B4300RM3
MPAI-B4450RM3 196 (7.6)
MPAI-B4150SM3
559 (22)
3670 (825) 2914 (655) 7340 (1650)MPAI-B4300SM3
MPAI-B4450SM3 393 (15)
