Page #105 background imageLoading...
Page #105 background image
Rockwell Automation Publication 520-UM001K-EN-E - August 2021 105
Chapter 3 Programming and Parameters
Communications Group (continued)
C171 [Drv 1 Addr] Related Parameter(s): C169
C172 [Drv 2 Addr]
C173 [Drv 3 Addr]
C174 [Drv 4 Addr]
Sets the corresponding node addresses of the daisy-chained drives when C169 [MultiDrv Sel] is set to 1 “Network Opt” or 2 “EtherNet/IP”. A reset or power cycle is required
after selection is made.
Values
Default:
Drv 1 Addr:
Drv 2 Addr:
Drv 3 Addr:
Drv 4 Addr:
2
3
4
5
Min/Max: 1/247
Display: 1
C175 [DSI I/O Cfg]
Sets the configuration of the Drives that are active in the multi-drive mode. Identifies the connections that would be attempted on a reset or power cycle. A reset or power
cycle is required after selection is made.
Options
0“Drive 0 (Default)
1“Drive 0-1
2“Drive 0-2
3“Drive 0-3
4“Drive 0-4
