Rockwell Automation Allen-Bradley PowerFlex 520 Series User Manual

178 Rockwell Automation Publication 520-UM001K-EN-E - August 2021
Appendix B Accessories and Dimensions
Bulletin 160 to PowerFlex 520-Series Mounting Adapter Plate
Item Description
B160
Frame
Size
Catalog No.
Mounting Adapter Plate
For use with drive when replacing Bulletin 160 drives in
existing installations to a PowerFlex 520-Series drive.
Select the catalog number based on the frame size of your
Bulletin 160 drive.
A25-MAP-FA
B25-MAP-FB
Mounting Adapter Plate for PowerFlex 4 AC Drive to PowerFlex 520-Series
Drive Ratings PowerFlex 4 PowerFlex 520-series
Input Voltage HP kW Catalog No.
Frame
Size
Catalog No.
Catalog No. with
external EMC Filter
(1)
(1) The adapter plate catalogs starting with 25-AP1-Fx are used to replace PowerFlex 4/40/40P IP20 drives with external EMC
filter to PowerFlex 520-series drives with external EMC filter only.
100 …120V,
Single-Phase,
50/60 Hz
0.3 0.2 22A-V1P5N104 A
25-AP0-FA 25-AP1-FA
0.5 0.4 22A-V2P3N104 A
1.0 0.8 22A-V4P5N104 B
25-AP0-FB 25-AP1-FB
1.5 1.1 22A-V6P0N104 B
200…240V,
Single-Phase,
50/60 Hz
0.3 0.2 22A-A1P5N104 A
25-AP0-FA 25-AP1-FA0.5 0.4 22A-A2P3N104 A
1.0 0.8 22A-A4P5N104 A
2.0 1.5 22A-A8P0N104 B 25-AP0-FB 25-AP1-FB
No Brake IGBT
0.3 0.2 22A-A1P4N103 A
25-AP0-FA 25-AP1-FA0.5 0.4 22A-A2P1N103 A
1.0 0.8 22A-A3P6N103 A
2.0 1.5 22A-A6P8N103 B
25-AP0-FB 25-AP1-FB
3.0 2.2 22A-A9P6N103 B
200…240V,
Single-Phase,
50/60 Hz, with
integral EMC
Filter
0.3 0.2 22A-A1P5N114 A
25-AP0-FA 25-AP1-FA0.5 0.4 22A-A2P3N114 A
1.0 0.8 22A-A4P5N114 A
2.0 1.5 22A-A8P0N114 B 25-AP0-FB 25-AP1-FB
No Brake IGBT
0.3 0.2 22A-A1P4N113 A
25-AP0-FA 25-AP1-FA0.5 0.4 22A-A2P1N113 A
1.0 0.8 22A-A3P6N113 A
2.0 1.5 22A-A6P8N113 B
25-AP0-FB 25-AP1-FB
3.0 2.2 22A-A9P6N113 B
200…240V,
Three-Phase,
50/60 Hz
0.3 0.2 22A-B1P5N104 A
25-AP0-FA 25-AP1-FA
0.5 0.4 22A-B2P3N104 A
1.0 0.8 22A-B4P5N104 A
2.0 1.5 22A-B8P0N104 A
3.0 2.2 22A-B012N104 B
25-AP0-FB 25-AP1-FB
5.0 3.7 22A-B017N104 B
380…480V,
Three-Phase
50/60 Hz
0.5 0.4 22A-D1P4N104 A
25-AP0-FA 25-AP1-FA1.0 0.8 22A-D2P3N104 A
2.0 1.5 22A-D4P0N104 A
3.0 2.2 22A-D6P0N104 B
25-AP0-FB 25-AP1-FB
5.0 3.7 22A-D8P7N104 B
