Rockwell Automation Publication 520-UM001K-EN-E - August 2021 179
Appendix B Accessories and Dimensions
Mounting Adapter Plate for PowerFlex 40 AC Drive to PowerFlex 520-Series
Drive Ratings PowerFlex 40 PowerFlex 520-series
Input Voltage HP kW Catalog No.
Frame
Size
Catalog No.
Catalog No. with
external EMC Filter
(1)
(1) The adapter plate catalogs starting with 25-AP1-Fx are used to replace PowerFlex 4/40/40P IP20 drives with external EMC
filter to PowerFlex 520-series drives with external EMC filter only.
100 …120V,
Single-Phase,
50/60 Hz
0.5 0.4 22B-V2P3N104 B
25-AP0-FB 25-AP1-FB1.0 0.8 22B-V5P0N104 B
1.5 1.1 22B-V6P0N104 B
200…240V,
Single-Phase,
50/60 Hz
0.5 0.4 22B-A2P3N104 B
25-AP0-FB 25-AP1-FB1.0 0.8 22B-A5P0N104 B
2.0 1.5 22B-A8P0N104 B
3.0 2.2 22B-A012N104 C 25-AP0-FC 25-AP1-FC
200…240V,
Single-Phase,
50/60 Hz, with
integral EMC
Filter
0.5 0.4 22B-A2P3N114 B
25-AP0-FB 25-AP1-FB1.0 0.8 22B-A5P0N114 B
2.0 1.5 22B-A8P0N114 B
3.0 2.2 22B-A012N114 C 25-AP0-FC 25-AP1-FC
200…240V,
Three-Phase,
50/60 Hz
0.5 0.4 22B-B2P3N104 B
25-AP0-FB 25-AP1-FB
1.0 0.8 22B-B5P0N104 B
2.0 1.5 22B-B8P0N104 B
3.0 2.2 22B-B012N104 B
5.0 3.7 22B-B017104 B
7.5 5.5 22B-B024N104 C 25-AP0-FC 25-AP1-FC
10.0 7.5 22B-B033N104 C 25-AP0-FD
-
(2)
(2) Mounting Adapter Plate is not required for the following ratings, as it comes with matching footprint and mounting holes.
• Three-Phase 200…240V: 7.5 kW/10 HP
• Three-Phase 380…480V: 11 kW/15 HP
• Three-Phase 500…600V: 11 kW/15 HP
380…480V,
Three-Phase
50/60 Hz
0.5 0.4 22B-D1P4N104 B
25-AP0-FB 25-AP1-FB
1.0 0.8 22B-D2P3N104 B
2.0 1.5 22B-D4P0N104 B
3.0 2.2 22B-D6P0N104 B
5.0 3.7 22B-D010N104 B
7.5 5.5 22B-D012N104 C
25-AP0-FC 25-AP1-FC
10.0 7.5 22B-D017N104 C
15.0 11.0 22B-D024N104 C 25-AP0-FD
-
(2)
525…600V,
Three-Phase
50/60 Hz
1.0 0.8 22B-E1P7N104 B
25-AP0-FB 25-AP1-FB
2.0 1.5 22B-E3P0N104 B
3.0 2.2 22B-E4P2N104 B
5.0 3.7 22B-E6P6N104 B
7.5 5.5 22B-E9P9N104 C
25-AP0-FC 25-AP1-FC
10.0 7.5 22B-E012N104 C
15.0 11.0 22B-E019N104 C 25-AP0-FD
-
(2)
