Appendix B Accessories and Dimensions
Replacement Parts
Mounting Adapter Plate for PowerFlex 40P AC Drive to PowerFlex 520-Series
Drive Ratings PowerFlex 40P PowerFlex 520-series
Input Voltage HP kW Catalog No.
Frame
Size
Catalog No.
Catalog No. with
external EMC Filter
(1)
(1) The adapter plate catalogs starting with 25-AP1-Fx are used to replace PowerFlex 4/40/40P IP20 drives with external EMC
filter to PowerFlex 520-series drives with external EMC filter only.
200…240V,
Three-Phase,
50/60 Hz
0.5 0.4 22D-B2P3N104 B
25-AP0-FB 25-AP1-FB
1.0 0.8 22D-B5P0N104 B
2.0 1.5 22D-B8P0N104 B
3.0 2.2 22D-B012N104 B
5.0 3.7 22D-B017N104 B
7.5 5.5 22D-B024N104 C 25-AP0-FC 25-AP1-FC
10.0 7.5 22D-B033N104 C 25-AP0-FD
-
(2)
(2) Mounting Adapter Plate is not required for the following ratings, as it comes with matching footprint and mounting holes.
• Three-Phase 200…240V: 7.5 kW/10 HP
• Three-Phase 380…480V: 11 kW/15 HP
• Three-Phase 500…600V: 11 kW/15 HP
380…480V,
Three-Phase 50/
60 Hz
0.5 0.4 22D-D1P4N104 B
25-AP0-FB 25-AP1-FB
1.0 0.8 22D-D2P3N104 B
2.0 1.5 22D-D4P0N104 B
3.0 2.2 22D-D6P0N104 B
5.0 3.7 22D-D010N104 B
7.5 5.5 22D-D012N104 C
25-AP0-FC 25-AP1-FC
10.0 7.5 22D-D017N104 C
15.0 11.0 22D-D024N104 C 25-AP0-FD
-
(2)
525…600V,
Three-Phase 50/
60 Hz
1.0 0.8 22D-E1P7N104 B
25-AP0-FB 25-AP1-FB
2.0 1.5 22D-E3P0N104 B
3.0 2.2 22D-E4P2N104 B
5.0 3.7 22D-E6P6N104 B
7.5 5.5 22D-E9P9N104 C
25-AP0-FC 25-AP1-FC
10.0 7.5 22D-E012N104 C
15.0 11.0 22D-E019N104 C 25-AP0-FD
-
(2)
PowerFlex 520-Series Power Module
Item Description
PowerFlex 520-Series
Power Module
Replacement power module for use with PowerFlex 520-Series drives. Includes:
• Power Module
• Power Module Front Cover
• Power Terminal Guard
•Heatsink Fan
Output Ratings
Input
Voltage Range
Frame
Size
Catalog No.Normal Duty Heavy Duty
Output
Current (A)
HP kW HP kW
100...120V AC (-15%, +10%) – 1-Phase Input, 0...230V 3-Phase Output
0.25 0.2 0.25 0.2 1.6 85...132 A 25-PM1-V1P6
0.5 0.4 0.5 0.4 2.5 85...132 A 25-PM1-V2P5
1.0 0.75 1.0 0.75 4.8 85...132 B 25-PM1-V4P8
1.5 1.1 1.5 1.1 6.0 85...132 B 25-PM1-V6P0
200...240V AC (-15%, +10%) – 1-Phase Input, 0...230V 3-Phase Output
0.25 0.2 0.25 0.2 1.6 170...264 A 25-PM1-A1P6
0.5 0.4 0.5 0.4 2.5 170...264 A 25-PM1-A2P5
1.0 0.75 1.0 0.75 4.8 170...264 A 25-PM1-A4P8
