182 Rockwell Automation Publication 520-UM001K-EN-E - August 2021
Appendix B Accessories and Dimensions
20.0 15.0 15.0 11.0 22.0 446...660 D 25-PM1-E022
25.0 18.5 20.0 15.0 27.0 446...660 E 25-PM1-E027
30.0 22.0 25.0 18.5 32.0 446...660 E 25-PM1-E032
PowerFlex 520-Series Control Module
Item Description
Frame
Size
Catalog No.
PowerFlex 523 Control
Module
Replacement control module for use with
PowerFlex 520-Series drives. Includes:
• Control Module
• Control Module Front Cover
A...E
25A-CTM1
PowerFlex 525 Control
Module
25B-CTM1
Other Parts
Item Description
Frame
Size
Catalog No.
PowerFlex 523 Control
Module Front Cover
Replacement cover for the control module I/O terminals,
EtherNet/IP, and DSI ports.
A...E
25A-CTMFC1
PowerFlex 525 Control
Module Front Cover
25B-CTMFC1
PowerFlex 520-Series
Power Module Front Cover
Replacement cover for the PowerFlex 520-Series power
module.
B25-PMFC-FB
C25-PMFC-FC
D25-PMFC-FD
E25-PMFC-FE
PowerFlex 520-Series
Power Terminal Guard
Replacement finger guard for power terminals.
A25-PTG1-FA
B25-PTG1-FB
C25-PTG1-FC
D25-PTG1-FD
E25-PTG1-FE
PowerFlex 520-Series
Heatsink Fan Kit
Replacement fan for drive power module.
A25-FAN1-FA
B25-FAN1-FB
C25-FAN1-FC
D25-FAN1-FD
E25-FAN1-FE
PowerFlex 520-Series EMC
Cores
Replacement EMC cores
A
25-CORE-A
25-CORE-RF-A
B
25-CORE-B
25-CORE-RF-B
C
25-CORE-C
25-CORE-RF-C
D
25-CORE-D
25-CORE-RF-D
E
25-CORE-E
25-CORE-RF-E
Output Ratings (Continued)
Input
Voltage Range
Frame
Size
Catalog No.Normal Duty Heavy Duty
Output
Current (A)
HP kW HP kW
