Rockwell Automation Publication 520-UM001K-EN-E - August 2021 183
Appendix B Accessories and Dimensions
Communication Option Kits and Accessories
Item Description Catalog No.
Communication Adapters
Embedded communication options for use with the
PowerFlex 520-Series drives:
• DeviceNet®
• Dual-port EtherNet/IP
•PROFIBUS DP-V1
25-COMM-D
25-COMM-E2P
25-COMM-P
25-ACCS-COMM
Compact I/Oâ„¢ Module Three channels 1769-SM2
Universal Serial Bus (USB)
Converter Module
Provides serial communication with DF1 protocol for use
with Connected Components Workbench software.
Includes:
• 2 m USB cable (1)
• 20-HIM-H10 cable (1)
• 22-HIM-H10 cable (1)
1203-USB
Serial Converter Module
(RS485 to RS232)
Provides serial communication with DF1 protocol for use
with Connected Components Workbench software.
Includes:
• DSI to RS232 serial converter (1)
• 1203-SFC serial cable (1)
• 22-RJ45CBL-C20 cable (1)
22-SCM-232
DSI Cable 2.0 m RJ45 to RJ45 cable, male to male connectors. 22-RJ45CBL-C20
Serial Cable
2.0 m serial cable with a locking low profile connector to
connect to the serial converter and a 9-pin sub-miniature
D female connector to connect to a computer.
1203-SFC
Splitter Cable RJ45 one to two port splitter cable (Modbus only) AK-U0-RJ45-SC1
Terminating Resistors RJ45 120 Ohm resistors (2 pieces) AK-U0-RJ45-TR1
Terminal Block RJ45 Two position terminal block (5 pieces) AK-U0-RJ45-TB2P
Connected Components
Workbench Software
(Download via the Software
Subscription Portal or DVD-
ROM)
rok.auto/ccw
Windows-based software packages for programming and
configuring Allen-Bradley® drives and other Rockwell
Automation products.
Compatibility:
Windows XP, Windows Vista and Windows 7
rok.auto/ccw
Bulletin 1321-3R Series Line Reactors
Output Ratings
(1)
Input Line Reactor
(2)(4)
Output Line Reactor
(2)(3)
Normal Duty Heavy Duty
IP00
(Open Style)
IP11
(NEMA/UL Type 1)
IP00
(Open Style)
IP11
(NEMA/UL Type 1)
HP kW HP kW Catalog No. Catalog No. Catalog No. Catalog No.
200...240V 50/60 Hz 1-Phase
(4)
0.25 0.2 0.25 0.2 1321-3R4-A 1321-3RA4-A 1321-3R2-D 1321-3RA2-D
0.5 0.4 0.5 0.4 1321-3R8-A 1321-3RA8-A 1321-3R2-D 1321-3RA2-D
1.0 0.75 1.0 0.75 1321-3R8-A 1321-3RA8-A 1321-3R4-A 1321-3RA4-A
2.0 1.5 2.0 1.5 1321-3R18-A 1321-3RA18-A 1321-3R8-A 1321-3RA8-A
3.0 2.2 3.0 2.2 1321-3R18-A 1321-3RA18-A 1321-3R12-A 1321-3RA12-A
200...240V 50/60 Hz 3-Phase
0.25 0.2 0.25 0.2 1321-3R2-D 1321-3RA2-D 1321-3R2-D 1321-3RA2-D
0.5 0.4 0.5 0.4 1321-3R2-D 1321-3RA2-D 1321-3R2-D 1321-3RA2-D
1.0 0.75 1.0 0.75 1321-3R4-A 1321-3RA4-A 1321-3R4-A 1321-3RA4-A
2.0 1.5 2.0 1.5 1321-3R8-A 1321-3RA8-A 1321-3R8-A 1321-3RA8-A
3.0 2.2 3.0 2.2 1321-3R12-A 1321-3RA12-A 1321-3R12-A 1321-3RA12-A
5.0 4.0 5.0 4.0 1321-3R18-A 1321-3RA18-A 1321-3R18-A 1321-3RA18-A
7.5 5.5 7.5 5.5 1321-3R25-A 1321-3RA25-A 1321-3R25-A 1321-3RA25-A
10.0 7.5 10.0 7.5 1321-3R35-A 1321-3RA35-A 1321-3R35-A 1321-3RA35-A
15.0 11.0 10.0 7.5 1321-3R45-A 1321-3RA45-A 1321-3R45-A 1321-3RA45-A
20.0 15.0 15.0 11.0
1321-3R55-A (ND)
1321-3R45-A (HD)
1321-3RA55-A (ND)
1321-3RA45-A (HD)
1321-3R55-A (ND)
1321-3R45-A (HD)
1321-3RA55-A (ND)
1321-3RA45-A (HD)
380...480V 50/60 Hz 3-Phase
