Rockwell Automation Publication 520-UM001K-EN-E - August 2021 81

Chapter 3 Programming and Parameters

Basic Display Group (continued)

b027 [Drive Temp]

Present operating temperature of the drive heatsink (inside module).

Values

Default: Read Only

Min/Max: 0/120 °C

Display: 1 °C

b028 [Control Temp]

Present operating temperature of the drive control.

Values

Default: Read Only

Min/Max: 0/120 °C

Display: 1 °C

b029 [Control SW Ver]

Current drive firmware version.

Values

Default: Read Only

Min/Max: 0.000/65.535

Display: 0.001
