3-78 Programming and Parameters
PowerFlex Digital DC Drive User Manual - Publication 20P-UM001C-EN-P - July 2008
152 Digital Out8 Sel Digital Outputs 3-68
154 Preset Speed 1 Discrete Speeds 3-23
155 Preset Speed 2 Discrete Speeds 3-23
156 Preset Speed 3 Discrete Speeds 3-23
157 Preset Speed 4 Discrete Speeds 3-23
158 Preset Speed 5 Discrete Speeds 3-23
159 Preset Speed 6 Discrete Speeds 3-23
160 Preset Speed 7 Discrete Speeds 3-23
162 Max Feedback Spd Motor Data 3-14
169 Encoder PPR Speed Feedback 3-19
175 Rated Motor Volt Motor Data 3-14
179 Nom Mtr Arm Amps Motor Data 3-14
181 Adaptive Spd En Adaptv Regulator 3-32
182 Adaptive Reg Typ Adaptv Regulator 3-32
183 Adaptive Ref Adaptv Regulator 3-32
184 Adaptive Spd 1 Adaptv Regulator 3-32
185 Adaptive Spd 2 Adaptv Regulator 3-32
186 Adaptive Joint 1 Adaptv Regulator 3-33
187 Adaptive Joint 2 Adaptv Regulator 3-33
188 Adaptive P Gain1 Adaptv Regulator 3-33
189 Adaptive I Gain1 Adaptv Regulator 3-33
190 Adaptive P Gain2 Adaptv Regulator 3-33
191 Adaptive I Gain2 Adaptv Regulator 3-33
192 Adaptive P Gain3 Adaptv Regulator 3-33
193 Adaptive I Gain3 Adaptv Regulator 3-33
199 Arm Current Pct Current Meters 3-12
200 Arm Current Current Meters 3-12
201 Drive Type Sel Motor Data 3-14
203 OverVolt Flt Cfg Alarms 3-53
209 Save HIM Ref HIM Ref Config 3-46
210 Man Ref Preload HIM Ref Config 3-46
211 Param Access Lvl Drive Memory 3-46
233 Output Voltage Drive Data 3-13
234 Fld Current Pct Torque Attribute 3-12
235 Elapsed Lifetime Drive Data 3-13
236 Spd Reg Out Pct Speed Regulator 3-11
242 Speed Reg En Speed Regulator 3-26
245 Speed Ramp En Ramp Rates 3-30
249 Save MOP Ref Reference Config 3-46
258 Reset Defaults Drive Memory 3-46
259 Anlg In1 Tune Analog Inputs 3-63
260 Anlg In2 Tune Analog Inputs 3-63
261 Anlg In3 Tune Analog Inputs 3-63
263 Clear Fault Que Faults 3-52
266 Jog Speed Discrete Speeds 3-23
267 TB Manual Ref Discrete Speeds 3-24
280 Nom Mtr Fld Amps Motor Data 3-14
295 Anlg In1 Target Analog Inputs 3-63
296 Anlg In2 Target Analog Inputs 3-63
297 Anlg In3 Target Analog Inputs 3-63
300 Drive Type Drive Data 3-13
331 Software Version Configuration 3-13
342 Torque Reduction Torque Attribute 3-17
344 Zero Ramp Output Ramp Rates 3-30
345 Zero Ramp Input Ramp Rates 3-30
346 Torque Positive Diagnostics 3-47
347 Torque Negative Diagnostics 3-47
348 Lock Speed Integ Speed Regulator 3-26
349 CurrLimit Active Diagnostics 3-47
351 Field Current Current Meters 3-12
353 Zero Torque Torque Attribute 3-17
354 Aux Inp Flt Cfg Alarms 3-53
365 OverTemp Flt Cfg Alarms 3-53
372 Spd Limit Active Diagnostics 3-47
373 Freeze Ramp Ramp Rates 3-30
No. Parameter Name Group Page
374 Drv Fld Brdg Cur Motor Data 3-14
378 Trim Ramp Pct Speed Reference 3-24
379 Trim Speed Pct Speed Reference 3-24
381 Drive Status 1 Diagnostics 3-48
382 Drive Status 2 Diagnostics 3-48
384 Spd Ref Out Pct Speed Meters 3-11
385 Speed Ref Out Speed Meters 3-11
388 Flying Start En Speed Regulator 3-27
393 Speed Threshold Diagnostics 3-49
394 At Speed Diagnostics 3-49
395 At Zero Speed Diagnostics 3-49
396 MOP Inc Active Diagnostics 3-49
397 MOP Dec Active Diagnostics 3-49
400 Spd Select 0 Diagnostics 3-49
401 Spd Select 1 Diagnostics 3-50
402 Spd Select 2 Diagnostics 3-50
403 Ramp Select 0 Diagnostics 3-50
404 Ramp Select 1 Diagnostics 3-50
414 Fdbk Device Type Speed Feedback 3-19
418 Real FF PID PID Control 3-36
420 Encoder Speed Speed Meters 3-11
421 PD Output PID PD Control 3-36
444 Spd Fdbk Filter Speed Regulator 3-27
445 Spd Up Gain Pct Speed Regulator 3-27
446 Speed Up Base Speed Regulator 3-27
447 Speed Up Filter Speed Regulator 3-27
452 CurrReg Autotune Autotune 3-20
453 Arm Resistance Autotune 3-20
454 Arm Inductance Autotune 3-20
455 Spd Fdbk Error Speed Feedback 3-19
456 Fld Weaken Ratio Field Config 3-15
457 Spd Fdbk Control Speed Feedback 3-19
458 SpdReg FB Bypass Speed Feedback 3-19
459 SpdReg Kp Bypass Speed Regulator 3-27
460 SpdReg Ki Bypass Speed Regulator 3-27
465 Drive Size Drive Data 3-13
466 AC Line Voltage Drive Data 3-13
467 Max Fld Curr Pct Field Config 3-15
468 Min Fld Curr Pct Field Config 3-15
469 Field Mode Sel Field Config 3-15
473 FldLoss Flt Cfg Alarms 3-54
478 Spd Loss Flt Cfg Alarms 3-54
481 UnderVolt Thresh Alarms 3-54
484 Scale1 Input Scale Blocks 3-39
485 Scale1 Output Scale Blocks 3-39
486 Scale1 Mul Scale Blocks 3-39
487 Scale1 Div Scale Blocks 3-39
488 Scale1 In Max Scale Blocks 3-39
489 Scale1 In Min Scale Blocks 3-39
490 Scale1 In Off Scale Blocks 3-40
491 Scale1 Out Off Scale Blocks 3-40
492 Scale1 In Abs Scale Blocks 3-40
493 Arm Volt Kp Speed Regulator 3-27
494 Arm Volt Ki Speed Regulator 3-27
495 Arm Volt Kp Base Speed Regulator 3-27
496 Arm Volt Ki Base Speed Regulator 3-27
497 Field Reg Enable Field Config 3-15
498 Force Min Field Field Config 3-15
499 Field Economy En Field Config 3-16
500 Field Ref Pct Current Meters 3-12
503 UserDefined0 User Defined 3-55
504 UserDefined1 User Defined 3-55
505 UserDefined2 User Defined 3-55
506 UserDefined3 User Defined 3-55
507 UserDefined4 User Defined 3-55
No. Parameter Name Group Page
