EN
49
4 Updates of version N6=17
• Improved management of control from the plug-in receiver
5 Technical characteristics of product
H70/104AC - 105AC/BOX H70/104AC/115 - H70/105AC/115
Mains power voltage 230 V~ ± 10% 50 Hz 115 V~ ± 10% 60 Hz
Maximum mains power absorption 650 W
Fuses
F1!*%:\QSXSVTS[IVGMVGYMXTVSXIGXMSR
F2 = F315mA 250 V (5x20) accessories power supply protection
Connectable motors 1
Motor power supply 230 V~ 115 V~
Motor type Single-phase asynchronous
Motor control type Triac phase control
Maximum power for 1 motor 600 W
1E\MQYQTS[IVƽEWLMRKPMKLX 40 W 230 V~ - 25 W 24 V~/dc (potential free contact)
Maximum power courtesy light 100 W 230 V~ - 25 W 24 V~/dc (potential free contact)
Gate open light power 2 W (24 V~)
Maximum accessory current absorption 6 W (24 V~) 300 mA
Operating temperature
-20°C +55°C
Degree of protection
IP00
IP54
(H70/105AC/BOX)
IP00
IP54
(H70/105AC/115/BOX)
Product dimension
mm 98x141x40 WeightOK
(H70/105AC/BOX 255x200x99)
