Roger Technology H70/104AC - Enable Limit Switches; Selecting Installattion Position of Motor Relative to Gate (Seen from Interior Side); Set Braking Force; Set Braking Time

EN
66

Enabled. The gate brakes before inverting direction when the control unit receives a close command
[LMPIXLIKEXIMWSTIRMRKSVERSTIRGSQQERH[LMPIXLIKEXIMWGPSWMRK
 
Set braking time
WARNING: check carefully that the chosen value is appropriate to the model of motor used.

Settable from 1 to 20 tenths of a second.
 
Set braking force
WARNING: preferably set low values to ensure that the gate stops correctly.

 = minimum force ...  = maximum force.
 
Selecting installation position of motor relative to gate (seen from interior side)

Motor installed on left.

Motor installed on right.
 
Enable limit switches
N.B.: MJXLMWTEVEQIXIVMWQSHMƼIHHMWGSRRIGXJVSQ:%'QEMRWTS[IV[EMXJSVXLIHMWTPE]XSXYVR
off then reconnect to mains power. Repeat acquisition procedure.

No limit switch installed.

Gate open and close limit switches installed.

Gate open limit switches installed.
 
'SRƼKYVMRKWIRWMRKIHKI COS1

Sensing edge NOT INSTALLED.

NC contact (normally closed). The gate reverses only when opening.

Contact with 8k2 resistor. The gate reverses only when opening.

NC contact (normally closed). The gate always reverses.

Contact with 8k2 resistor. The gate always reverses.
 
'SRƼKYVMRKWIRWMRKIHKI COS2

Sensing edge NOT INSTALLED.

NC contact (normally closed). The gate reverses only when closing.

Contact with 8k2 resistor. The gate reverses only when closing.

NC contact (normally closed). The gate always reverses.

Contact with 8k2 resistor. The gate always reverses.
 
'SRƼKYVIIRGSHIV
N.B.:MJRSIRGSHIVMWMRWXEPPIHXMQIFEWIHGSRXVSPMWYWIH
MJXLMWTEVEQIXIVMWQSHMƼIHHMWGSRRIGXJVSQ:%'QEMRWTS[IV[EMXJSVXLIHMWTPE]XSXYVRSJJ
then reconnect to mains power. Repeat acquisition procedure.

No encoder installed.

Optical encoders installed (8 pulses/revolution).

Magnetic encoders installed (1 pulse/revolution). Only the E30 series uses magnetic encoders.
 
'SRƼKYVMRKVEHMSGLERRIP46
 
'SRƼKYVMRKVEHMSGLERRIP46

STEP MODE.

PARTIAL OPENING

OPENING

CLOSING.

STOP.
