Rotax 912 Series Service Manual

00-00-00
page 26
May 01/2007
Effectivity 912/914 Series
Edition 1 / Rev. 0
d02620
BRP-Rotax
Maintenance Manual
Dimensional check of parts
See Fig. 00-2
Take readings of all parts listed in the dimension sheets.
Enter the respective actual value in the dimension sheets attached directly after
each section.
■ CAUTION: Where measurement values are taken in hundredths of a
millimeter or more precisely, the temperature of the part must
be 20 to 25 °C (68 to 77 °F).
07437
Fig. 00-2
8.2) List of abbreviations
The following table shows the abbreviations used for the control points.
Abbreviations for control points
08216
Abbreviation Description
AL
al
ternator
CA
ca
mshaft
CC
c
rank
c
ase
CH
c
ylinder
h
ead
CR
c
on
r
od
CS
c
rank
s
haft
CY
cy
linder
EL
el
ectric
ES
e
lectric
s
tarter
EX
ex
haust
GB
g
ear
b
ox
GO
go
vernor
OP
o
il
p
ump
PI
pi
ston
PP
p
iston
p
in
ST
st
ator
TC
t
urbo
c
harger
VT
v
alve
t
rain
WP
w
ater
p
ump

Rotax 912 Series Specifications

General

Redline	5800 rpm
TBO	2000 hours
Displacement	1211 cc
Bore	79.5 mm
Stroke	61 mm
Power Output	80 hp (59.6 kW)
Compression Ratio	9.0:1
Fuel Type	Avgas 100LL
Ignition System	Dual electronic ignition
Fuel System	Fuel Injected
Oil System	Dry sump
Engine Type	4-cylinder, horizontally opposed, 4-stroke
