Rotax 912 Series Service Manual

74-00-00
page 62
May 01/2007
Effectivity 912/914 Series
Edition 1 / Rev. 0
d02624
BRP-Rotax
Maintenance Manual
07201
Description
Code
Reading new
wear
limit
wear
limit
Readings
min max 100% 50%
Spark plug
Elektrodenabstand SP01
0,6
0,022
0,7
0,028
0,9
0,036
actual
renewed
Ignition housing
A 1/2 A 3/4 B 1/2 B 3/4
trigger coil gap "old
type"
IH02
0,4
0,016
0,5
0,020
actual
renewed
trigger coil gap (with
clamps)
IH02
0,3
0,012
0,4
0,016
actual
renewed
trigger coil axial off-
set
IH03
0,0
0,000
0,2
0,008
actual
renewed
External alternator
Deflection of V-belt
at a force of 50 N
AL01
6,0
0,236
actual
renewed

Rotax 912 Series Specifications

General

Redline	5800 rpm
TBO	2000 hours
Displacement	1211 cc
Bore	79.5 mm
Stroke	61 mm
Power Output	80 hp (59.6 kW)
Compression Ratio	9.0:1
Fuel Type	Avgas 100LL
Ignition System	Dual electronic ignition
Fuel System	Fuel Injected
Oil System	Dry sump
Engine Type	4-cylinder, horizontally opposed, 4-stroke
